SS304 DN400 Welded Stainless Steel Tubes Pipe Austenitic Mill Finish

SS304  DN400 Welded Stainless Steel Tubes Pipe Austenitic Mill Finish
SS304  DN400 Welded Stainless Steel Tubes Pipe Austenitic Mill Finish SS304  DN400 Welded Stainless Steel Tubes Pipe Austenitic Mill Finish SS304  DN400 Welded Stainless Steel Tubes Pipe Austenitic Mill Finish

Large Image :  SS304 DN400 Welded Stainless Steel Tubes Pipe Austenitic Mill Finish

Product Details:
Place of Origin: zhejiang
Brand Name: XINFUTIAN
Certification: ISO,BV
Model Number: 409L
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiation
Packaging Details: Standard Seaworthy package or as the customer's requirement
Delivery Time: 5-10 working days
Supply Ability: 1000 Ton Per Month
Detailed Product Description
Name: Stainless Steel Welded Tube Size: DN25-DN1200
Service: OEM/ODM, OEM, 24 Hours Online Type: Welded, Round Pipe / Tube
Feature: Better Mechanical Property Outer Diameter: 6-630mm, Customized
High Light:

DN400 Stainless Steel Welded Tube

,

SS304 Stainless Steel Welded Tube

,

DN400 stainless steel welded pipe

Large Diameter Welded Stainless Steel Tubes SS304 Pipe 400BN



Manufacture:
In order to comply with this specification welded stainless steel tube must be manufactured by an automatic welding process using no filler metal, or it must be a seamless pipe. If a welded stainless steel tube has a nominal pipe size greater than 14'' then it may be constructed from two longitudinal sections, and hence have two longitudinal welds. The pipe may be either hot finished or cold finished.

Product description

Name Austenitic Mill Finish Stainless Steel Welded Tube Stainless Steel Seamless Tube
Items Round tubes ,welded
Standard ASTM ,GB,DIN AISI
Material Grade 316L:Ni 10%, Cr 16%
304L: Ni 8%, Cr 18%
304: Ni 8%, Cr 18%
Outer Diameter Round pipe9.5mm--813mm
square 12.7x12.7--200X200mm
rectangular 20X40--150X200mm
Thickness 0.8mm - 34mm
Length 5.8m,6m, or as customers' request
Tolerance a) Outer Diameter: +/- 0.2mm
b) Thickness: +/- 0.02mm
c) Length: +/- 5mm
Surface annealing,pickling
  sandblasting
Application industry,exhausting,water
Test Squash test, extended test, water pressure test,heat treatment, NDT
Chemical Composition of Material Material 304L 316L 304
C ≤0.035 ≤0.035 ≤0.08
Si ≤1.00 ≤1.00 ≤1.00
Mn ≤2.00 ≤2.00 ≤2.00
P ≤0.045 ≤0.045 ≤0.045
S ≤0.03 ≤0.03 ≤0.03
Cr 18-20 16-18 18-20
N 8-12.0 10-14 8-10.5
Mechanical Property Material Item 304L 316L 304
Tensile Strength ≥515 ≥515 ≥515
Yield Strength ≥205 ≥205 ≥205
Extension ≥35% ≥35% ≥35%
Hardness (HV) N/M N/M N/M



Finish and repair:


The surface of the welded stainless steel tube must be clean and free of scale and contaminating iron particles. It can be bright annealed but may be pickled, blasted or can be passivated.
Repair by welding. Permitted on <−20% of the weld seam length of welded stainless steel tube if >−NPS 6 and having a wall thickness >−0.200 in (mm). Tungsten-arc welding process is used for repairs, with filler metal to a grade as specified in A 312 (not repeated here). Weld repairs must be identified on the pipe and in test certificate.



SS304  DN400 Welded Stainless Steel Tubes Pipe Austenitic Mill Finish 0

SS304  DN400 Welded Stainless Steel Tubes Pipe Austenitic Mill Finish 1
