SS NO1 Jis 317l Stainless Steel Sheet Corrosion Resistance Acid White

Certification
China WUXI XINFUTIAN METAL PRODUCTS CO., LTD certification
China WUXI XINFUTIAN METAL PRODUCTS CO., LTD certification
Vey good BA and HL Finish ,and the same time good package to protect the goods

—— Sam-USA

Fast delivery time,good quality From WUXI XINFUTIAN METAL PRODUCTS CO.,LTD ,hope to have a win-win business in the future .

—— Fathiha-UAE

We Have Cooperation With this Factory Many Years , Everything Goes Very Well.l Like This Factory !

—— Abbas-Pakistan

Good quality and pacakge ,especially good after -service

—— Raja-Qatar

First time cooperation with XFT METAL ,Sara ,good experience with XFT ,good quality ,good service

—— Mert

Fast delivery time,good quality From XFT METAL ,hope to have more cooperation with them in the future

—— Cara

I'm Online Chat Now

SS NO1 Jis 317l Stainless Steel Sheet Corrosion Resistance Acid White

SS NO1 Jis 317l Stainless Steel Sheet Corrosion Resistance Acid White
SS NO1 Jis 317l Stainless Steel Sheet Corrosion Resistance Acid White SS NO1 Jis 317l Stainless Steel Sheet Corrosion Resistance Acid White SS NO1 Jis 317l Stainless Steel Sheet Corrosion Resistance Acid White SS NO1 Jis 317l Stainless Steel Sheet Corrosion Resistance Acid White

Large Image :  SS NO1 Jis 317l Stainless Steel Sheet Corrosion Resistance Acid White

Product Details:
Place of Origin: Shanxi
Brand Name: TISCO
Certification: ISO 9001:2008
Model Number: 317L
Payment & Shipping Terms:
Minimum Order Quantity: 1 TON
Price: Negotiation
Packaging Details: With wooden pallets, Standard Sea Worthy Package
Delivery Time: 7-15 Working days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 1000TON / MONTH
Detailed Product Description
Name: 317l Stainless Steel Sheet Surface: BA / 2B / NO.1 / NO.3 / NO.4
Application: Construction, Industry, Decoration Standard: ASTM, AISI, DIN, EN, JIS
MTC: Can Be Offered Sample: Corrosion Resistance
High Light:

Jis 317l stainless steel plate

,

NO1 stainless steel 317 sheet

SS NO1 Jis 317l Stainless Steel Sheet Corrosion Resistance

About products

317L is a molybdenum containing, low carbon austenitic stainless steel with increased additions of chromium, nickel, and molybdenum for better corrosion resistance and increased resistance to chemical attack for sulfurous, acetic, formic, citric, and tartaric acids. Due to its low carbon content, 317L also provides resistance to sensitization when welded and higher creep, stress to rupture, and tensile strength at elevated temperatures. It is non-magnetic in the annealed condition but may become slightly magnetic after welding.

Package

1 Sheets covered with wooden plate for protection in transportation.
2. All sheets will be loaded in strong wooden packages.
3. Every cartons loaded with good shoring and strengthening.
4. Take container loading pictures and seal the container.

Surface Finish

A. NO1 thickness :3.0mm~150.0m
Characteristics:Finished by hot-rolling, annealing and pickling, characterized by white pickled surface
Aplication: Chemical industry equipment,Industrial tanks

B. 2B thickness :0.2mm~6.0m
Characteristics:Finished by heat treatment, pickling after cold rolling, followed by skin pass line to be more brighter and smooth surface
Aplication: General Application Medical Instruments,Tableware

C. BA thickness :0.5mm~30.0mm
Characteristics:Bright heat treatment after cold rolling
Aplication: Kitchen utensil, kitchen ware,architectural purpose


D. No4 thickness :0.4mm~3.0mm
Characteristics:Polishing with No.150 to No180 mesh abrasives The most popular finishes
Aplication: Milk & Food processing acilities, Hospital Equipment, Bath-tub

Chemical Composition



Material C Si Mn P S Cr

Ni


201 ≤0.12 ≤0.75 9.5-12.5 ≤0.045 ≤0.03 13-16

0.8-1.5


304 ≤0.08 ≤0.75 ≤2.0 ≤0.045 ≤0.03 18-19

8-10


316 ≤0.08 ≤1.00 ≤2.0 ≤0.035 ≤0.03 10-14

16.0-18.5


430 ≤0.12 ≤0.75 ≤2.0 ≤0.04 ≤0.03 16-18

≤0.6


Containers:

20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)
40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)
40ft HC:12032mm(Lengh)x2352mm(Width)x2698mm(High)
20' container load 25tons goods whose length is under 5.8m
40' container load 25tons goods whose length is under11.8m

SS NO1 Jis 317l Stainless Steel Sheet Corrosion Resistance Acid White 0

SS NO1 Jis 317l Stainless Steel Sheet Corrosion Resistance Acid White 1
