products details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
Stainless Steel Plate
Created with Pixso.

SS NO1 Jis 317l Stainless Steel Sheet Corrosion Resistance Acid White

SS NO1 Jis 317l Stainless Steel Sheet Corrosion Resistance Acid White

Brand Name: TISCO
Model Number: 317L
MOQ: 1 TON
Price: Negotiation
Payment Terms: T/T, L/C, Western Union
Supply Ability: 1000TON / MONTH
Detail Information
Place of Origin:
Shanxi
Certification:
ISO 9001:2008
Name:
317l Stainless Steel Sheet
Surface:
BA / 2B / NO.1 / NO.3 / NO.4
Application:
Construction, Industry, Decoration
Standard:
ASTM, AISI, DIN, EN, JIS
MTC:
Can Be Offered
Sample:
Corrosion Resistance
Packaging Details:
With wooden pallets, Standard Sea Worthy Package
Supply Ability:
1000TON / MONTH
Highlight:

Jis 317l stainless steel plate

,

NO1 stainless steel 317 sheet

Product Description

SS NO1 Jis 317l Stainless Steel Sheet Corrosion Resistance

About products

317L is a molybdenum containing, low carbon austenitic stainless steel with increased additions of chromium, nickel, and molybdenum for better corrosion resistance and increased resistance to chemical attack for sulfurous, acetic, formic, citric, and tartaric acids. Due to its low carbon content, 317L also provides resistance to sensitization when welded and higher creep, stress to rupture, and tensile strength at elevated temperatures. It is non-magnetic in the annealed condition but may become slightly magnetic after welding.

Package

1 Sheets covered with wooden plate for protection in transportation.
2. All sheets will be loaded in strong wooden packages.
3. Every cartons loaded with good shoring and strengthening.
4. Take container loading pictures and seal the container.

Surface Finish

A. NO1 thickness :3.0mm~150.0m
Characteristics:Finished by hot-rolling, annealing and pickling, characterized by white pickled surface
Aplication: Chemical industry equipment,Industrial tanks

B. 2B thickness :0.2mm~6.0m
Characteristics:Finished by heat treatment, pickling after cold rolling, followed by skin pass line to be more brighter and smooth surface
Aplication: General Application Medical Instruments,Tableware

C. BA thickness :0.5mm~30.0mm
Characteristics:Bright heat treatment after cold rolling
Aplication: Kitchen utensil, kitchen ware,architectural purpose


D. No4 thickness :0.4mm~3.0mm
Characteristics:Polishing with No.150 to No180 mesh abrasives The most popular finishes
Aplication: Milk & Food processing acilities, Hospital Equipment, Bath-tub

Chemical Composition



Material C Si Mn P S Cr

Ni


201 ≤0.12 ≤0.75 9.5-12.5 ≤0.045 ≤0.03 13-16

0.8-1.5


304 ≤0.08 ≤0.75 ≤2.0 ≤0.045 ≤0.03 18-19

8-10


316 ≤0.08 ≤1.00 ≤2.0 ≤0.035 ≤0.03 10-14

16.0-18.5


430 ≤0.12 ≤0.75 ≤2.0 ≤0.04 ≤0.03 16-18

≤0.6


Containers:

20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)
40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)
40ft HC:12032mm(Lengh)x2352mm(Width)x2698mm(High)
20' container load 25tons goods whose length is under 5.8m
40' container load 25tons goods whose length is under11.8m
