ASTM A312 / A249 304 316L Seamless Steel Pipe Pickled Industrial 8" Sch80

China ASTM A312 / A249 304 316L Seamless Steel Pipe Pickled Industrial 8" Sch80 supplier
ASTM A312 / A249 304 316L Seamless Steel Pipe Pickled Industrial 8" Sch80 supplier ASTM A312 / A249 304 316L Seamless Steel Pipe Pickled Industrial 8" Sch80 supplier ASTM A312 / A249 304 316L Seamless Steel Pipe Pickled Industrial 8" Sch80 supplier

Large Image :  ASTM A312 / A249 304 316L Seamless Steel Pipe Pickled Industrial 8" Sch80

Product Details:

Place of Origin: Shanghai,China
Brand Name: Baosteel
Certification: ISO,
Model Number: 304,316L

Payment & Shipping Terms:

Minimum Order Quantity: 1 Ton
Price: Negotiation
Packaging Details: Plastic bag in bundle,Wooden box,etc.
Delivery Time: 7-15 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 600Tons/Month
Contact Now
Detailed Product Description
Surface: Acid White Surface Length: 6m Or Customer Request
OD: 14MM Or Customer Thickness: 3MM Or Customer
Sample: Can Be Provide Moq: 1 Ton



ASTM A312 / A249 304 316L Seamless Steel Pipe Pickled Industrial 8" Sch80



300 Series SS Smls Pipe, 2205 309S 310S 904L

Seamless Stainless Steel Pipe,Annealed And Pickled



Quick Detail:





ASTM A249 Dimension tolerance table
Outside Diameter Thickness Length
<25.4mm ±0.10mm ±10% OD<50.8mm +3.0mm-0mm
OD≥50.8mm +5.0mm-0mm
≥25.4~38.1mm ±0.15mm
≥38.1~50.8mm ±0.20mm
≥50.8~63.5mm ±0.25mm
≥63.5~76.2mm ±0.30mm
≥76.2~101.6mm ±0.38mm
≥101.6~190.5mm +0.38mm -0.64mm
≥190.5~228.6mm +0.38mm -1.14mm





TM TP304 ≤0.08
≤0.035
≤0.08
≤0.035
≤1.00
≤1.00
≤1.00
≤1.00
≤2.00
≤2.00
≤2.00
≤2.00
≤0.045
≤0.045
≤0.045
≤0.045
≤0.03
≤0.03
≤0.03
≤0.03
8.00~11.00
8.00~13.00
10.00~14.00
10.00~14.00
18.00~20.00
18.00~20.00
16.00~18.00
16.00~18.00
2.00~3.00
2.00~3.00
TP304L
TP316
TP316L



Hot Rolled Seamless Steel Tube
Hot rolled seamless steel pipe is divided as one of seamless steel tubes according to production methods.Hot rolling is relative to the case of cold rolling, cold rolling was conducted at room temperature and hot rolling is carried out above the recrystallization temperature rolling. Welded steel pipe and seamless steel pipe, seamless steel pipe is usually made of round steel perforated reprocessing, welded steel pipe are usually made of steel plate welded together by different ways.
Hot rolled seamless steel tube diameter is usually over 38 mm.Smaller diameter seamless steel tube can be obtained by means of cold rolled or cold drawn.



Hot rolled seamless steel tube process
Hot rolled seamless steel tube in automatic pipe mill production unit.Solid billet through inspection and clear the surface defects, cut into the required length, centering on the tube billet perforation end face, and then sent to a heating furnace, punched on the punch.In perforated revolve and progress at the same time, under the action of roll and head, tube billet internal cavity formed gradually, according to the capillary.Then sent to automatically continue rolling mill.Finally approved by reeling mill all the whole wall thickness, the sizing sizing machine, to meet the specification requirements.Using continuous rolling pipe unit production of hot-rolled seamless steel tube is more advanced methods, usually process is: through hot rolled seamless steel pipe: the circular tube billet - heat - punch - three-roll skew rolling, rolling, or pressing - to take off the tube and sizing (or reducing) - cooling - the tube billet - straightening - hydrostatic test (or inspection) to tags, put in storage.



ASTM A312/DIN17456/JIS G3459 stainless steel seamless pipe, cold drawn/cold rolledASTM A312/A213 TP310,TP310S,TP347,TP347H,TP321H seamless pipe / tubing .

ASTM A312 / A249 304 316L Seamless Steel Pipe Pickled Industrial 8" Sch80ASTM A312 / A249 304 316L Seamless Steel Pipe Pickled Industrial 8" Sch80
