| Place of Origin: | Shanghai |
|---|---|
| Brand Name: | Baosteel |
| Certification: | ROHS |
| Model Number: | 310S |
| Minimum Order Quantity: | negotiation |
| Price: | Negotiation |
| Packaging Details: | Each Hairline finished stainless steel 201 square pipe will be sleeved in the plastic bags, then packed as a bundle. then Iron box, wooden box and plywood box can be customized, which is seaworthy. or Pack as your request. |
| Delivery Time: | 7-20 Working days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 1000 Ton Per Month |
| Name: | Stainless Steel Rectangular Tubing | Shape: | Square / Rectangular / Oval Etc |
|---|---|---|---|
| Polish: | 400# / 600# / 800# | Thickness: | 1-30MM |
| Grade: | 310S Stainless Steel | Outer Diameter: | 6-350MM |
| Standard: | ASTM, EN, JIS | ||
| High Light: | seamless stainless steel tubing,ss 304 seamless pipe |
||
Durable Stainless Steel Rectangular Tubing , 310S Stainless Steel Pipe
Stainless Steel Rectangular Tubing Introduction
1. A999/A999M: Each pipe shall be subjected to the nondestructive electric test or the hydrostatic test, the pipe of test to be used shall be at the option of the mfg, unless otherwise specified in the PO.
2. The Pipe lengths : Unless otherwise agreed upon, all size from NPS 1/8” TO AND INCLUDING nps 8 are available in a length up to 24ft with the permitted range of 15 to 24 ft. Short length are acceptable and the number and min, length shall be agreed upon between mfg and purchaser.
3. The finished pipe shall be reasonably straight and shall have workmanlike finish, Removal of imperfections by grinding is permitted, provided the W.T are not decreased to the less than the permitted in Section 9 of Specification A999/A999M
4. Butt Weld End: According to ANSI B 16.25
5. Pipe Marking: Specified in A999/999M, include “Logo+Standard+SIZE+Heat No.+Lot No.+H.T/E.T/U.T”
6. Packing: Each Pipe end is protected by Plastic cap. Then packed by Anti-rust steel strip, The outside of the bundle is plastic woven bag, or Plastic film.
Stainless Steel Rectangular Tubing Parameters
| Name | Durable Stainless Steel Rectangular Tubing , 310S Stainless Steel Pipe | |||||
| Standard | ASTM A554,ASTM A312 | |||||
| Material Grade | 201,202,304,316,316L,430 | |||||
|
Main Material
|
a) 201 (Ni0.8%-1%) b) 202 (Ni: 3.0%-4.0%) d) 316 (Ni: 10% Cr: 18%) |
|||||
| Size Range | 139mm-1600mm ETC. | |||||
| Thickness | 0.5-30mm | |||||
| Length | 6m or as customers' request | |||||
|
Tolerance |
a) Outer Diameter: +/- 0.2mm | |||||
| b) Thickness: +/- 0.02mm | ||||||
| c) Length: +/- 5mm | ||||||
| Surface |
180G, 320G Satin/Hairline 400G, 600G Mirror finish |
|||||
| Application | handrail,railing, staircase, weldmesh screen,door,window, balcony,fence,bench,furniture,etc | |||||
| Test | Squash test, extended test, water pressure test, crystal rot test, heat treatment, NDT | |||||
|
Chemical Composition of Material |
Material
Composition |
201 | 202 | 304 | 316L | 430 |
| C | ≤0.15 | ≤0.15 | ≤0.08 | ≤0.035 | ≤0.12 | |
| Si | ≤1.00 | ≤1.00 | ≤1.00 | ≤1.00 | ≤1.00 | |
| Mn | 5.5-7.5 | 7.5-10 | ≤2.00 | ≤2.00 | ≤1.00 | |
| P | ≤0.06 | ≤0.06 | ≤0.045 | ≤0.045 | ≤0.040 | |
| S | ≤0.03 | ≤0.03 | ≤0.030 | ≤0.030 | ≤0.030 | |
| Cr | 13-15 | 14-17 | 18-20 | 16-18 | 16-18 | |
| Ni | 0.7-1.1 | 3.5-4.5 | 8-10.5 | 10-14 | ||
| Mo | 2.0-3.0 | |||||
|
Mechanical Property |
Material Item | 201 | 202 | 304 | 316 | |
| Tensile Strength | ≥535 | ≥520 | ≥520 | ≥520 | ||
| Yield Strength | ≥245 | ≥205 | ≥205 | ≥205 | ||
| Extension | ≥30% | ≥30% | ≥35% | ≥35% | ||
| Hardness (HV) | <105 | <100 | <90 | <90 | ||
MAIN PRODUCTION STANDARDS:
|
STANDARD TYPE
|
STANDARD |
|
EN |
EN10216-5 , EN10216-2 |
|
DIN
|
DIN 17456 , DIN 17458 |
|
ASTM
|
ASTM A312, A213, A269, A511, A789, A790 ETC |
|
GOST |
GOST 9941 , GOST 5632 |
|
JIS
|
JIS G3459 , JIS G3463 |
|
GB
|
GB/T14975,GB/T14975, GB13296, GB5310, GB9948 |
Stainless Steel Rectangular Tubing Details
