Cold Rolled Hot Rolled Stainless Steel Welded Tube ASTM A312 ASTM A213

Brand Name:	XINFUTIAN
Model Number:	316l，304
MOQ:	Negotiation
Price:	Negotiation
Payment Terms:	D/A, L/C, T/T
Supply Ability:	1000 ton/Month

Detail Information

Product Description

Detail Information

Place of Origin:

WUXI,WENZHOU

Certification:

BV,SGS

Type:

Stainless Steel Welded Tube

Thickness:

0.4-30mm,0.5-100mm,0.25-2.5mm

Length:

According To Customer's Request

Technique:

Cold Rolled Hot Rolled

Material:

200 Series/300 Series/400series

Certification:

ASTM A312 ASTM A213

Shape:

Round Section, Slot, Round / Square / Rectangular / Oval Etc

Packaging Details:

Plastic bags

Supply Ability:

1000 ton/Month

Highlight:

stainless steel rectangular tubing

duplex stainless steel pipe

Product Description

Cold Rolled Hot Rolled Stainless Steel Welded Tube ASTM A312 ASTM A213

Stainless Steel Welded Tube introduction

316 stainless steel pipe is a kind of hollow long round steel, which is widely used in petroleum, chemical industry, medical treatment, food, light industry, mechanical instrument and other industrial transportation pipes and mechanical structural components. In addition, bending, torsional strength of the same weight, so it is also widely used in the manufacture of mechanical parts and engineering structures. Also commonly used for the production of conventional weapons, barrels, shells, etc.

1. Grade:TP304 TP304L TP316L TP317L TP310S 904L 2205 2507

2. Size:19-720MM

3. Standard: ASTM A312 ASTM A213 ASTM A269

4. Certification: ISO9001, SGS

Stainless Steel Welded Tube Size

Normal Pipe Size		Outside Diameter	Normal Wall Thickness
NPS	DN	OD		SCH10s	SCH40s	STD	SCH40	XS	SCH80s
1/8	6	10.3	-	1.24	1.73	1.73	1.73	2.41	2.41
1/4	8	13.7	-	1.65	2.24	2.24	2.24	3.02	3.02
3/8	10	17.1	-	1.65	2.31	2.31	2.31	3.2	3.2
1/2	15	21.3	1.65	2.11	2.77	2.77	2.77	3.73	3.73
3/4	20	26.7	1.65	2.11	2.87	2.87	2.87	3.91	3.91
1	25	33.4	1.65	2.77	3.38	3.38	3.38	4.55	4.55
1 1/4	32	42.2	1.65	2.77	3.53	3.53	3.53	4.85	4.85
1 1/2	40	48.3	1.65	2.77	3.68	3.68	3.68	5.08	5.08
2	50	60.3	1.65	2.77	3.91	3.91	3.91	5.54	5.54
2 1/2	65	73	2.11	3.05	5.16	5.16	5.16	7.01	7.01
3	80	88.9	2.11	3.05	5.49	5.49	5.49	7.62	7.62
3 1/2	90	101.6	2.11	3.05	5.74	5.74	5.74	8.08	8.08
4	100	114.3	2.11	3.05	6.02	6.02	6.02	8.56	8.56
5	125	141.3	2.77	3.4	6.55	6.55	6.55	9.53	9.53
6	150	168.3	2.77	3.4	7.11	7.11	7.11	10.97	10.97

Product Name	Stainless Steel welded Pipes
Standard	ASTM A312 ASTM A213 ASTM A269
Material	Stainless Steel
Grade	TP304 TP304L TP316LTP316 Ti TP317L TP310S 904L 2205 2507
Size	19-720MM
Brande	"DONGFENG"
Technology	Hot rolling or Cold drawing
Used	Petroleurn/Chemical /Natgas/Building
