| Place of Origin: | Jiangsu |
|---|---|
| Brand Name: | XINFUTIAN |
| Certification: | ISO,BV |
| Model Number: | 65#,70#,82b high carbon spring wire |
| Minimum Order Quantity: | 5 ton |
| Price: | Negotiation |
| Packaging Details: | Standard Seaworthy package or as the customer's requirement |
| Delivery Time: | 5-10 working days |
| Supply Ability: | 1000 Ton Per Month |
| Product Name: | High Carbon Spring Steel Wire | Tolerance: | ±1% |
|---|---|---|---|
| Feature: | Acid-resisting, Heat-resisting | Technique: | Cold Drawn/cold Rolled/hot Rolled |
| Diameter: | 0.3mm---12.5mm | Special Use: | Free Cutting Steel |
| High Light: | 0.3mm High Carbon Steel Wire,0.3mm high carbon wire,Q195 High Carbon Steel Wire |
||
| Certificate | ISO9001/SGS/BV |
| Material | Q195 Q235 45# 60# 65# 70# 80# 82B carbon steel |
| Key word | cold drawn high carbon spring steel wire |
| Diameter | 0.3mm---12.5mm |
| Surface treatment | phosphate Carbon Carbon Wire TO Oil Tempered cold drawn high carbon spring steel wire |
| Price Term | FOB, CFR, CIF,LC |
| Package |
Standard export packing. In coils, water-proof cloth.Z2 packaging,wooden reel, Or according to customer's needs. |
| Tensile strength | low/mild/high TO In Roll cold drawn high carbon spring steel wire |
| Port of loading | Wuxi,China |
| Application | spring/air hose/mattress/cable |
| Certificate | ISO9001/SGS/BV |
| Material | Q195 Q235 45# 60# 65# 70# 80# 82B carbon steel |
| Key word | cold drawn high carbon spring steel wire |
| Diameter | 0.3mm---12.5mm |
| Surface treatment | phosphate Carbon Carbon Wire TO Oil Tempered cold drawn high carbon spring steel wire |
| Price Term | FOB, CFR, CIF,LC |
| Package |
Standard export packing. In coils, water-proof cloth.Z2 packaging,wooden reel, Or according to customer's needs. |
| Tensile strength | low/mild/high TO In Roll cold drawn high carbon spring steel wire |
| Port of loading | zhejiang,China |
| Application | spring/air hose/mattress/cable |
| Carbon spring steel wires | |||
| Suitable for using the springs in machinery | GB4357-1989 | ||
| Diameter mm | Tensile Strength ,MPa | ||
| B | C | D | |
| 0.22 | 2110-2500 | 2350-2750 | 2690-3090 |
| 0.25 | 2060-2450 | 2300-2700 | 2640-3040 |
| 0.28 | 2010-2400 | 2300-2700 | 2640-3040 |
| 0.30 | 2010-2400 | 2300-2700 | 2640-3040 |
| 0.32 | 1960-2350 | 2250-2650 | 2600-2990 |
| 0.35 | 1960-2350 | 2250-2650 | 2600-2990 |
| 0.40 | 1910-2300 | 2250-2650 | 2600-2990 |
| 0.45 | 1860-2260 | 2200-2600 | 2550-2940 |
| 0.50 | 1860-2260 | 2200-2600 | 2550-2940 |
| 0.55 | 1810-2210 | 2150-2550 | 2500-2890 |
| 0.60 | 1760-2160 | 2110-2500 | 2450-2840 |
| 0.63 | 1760-2160 | 2110-2500 | 2450-2840 |
| 0.70 | 1710-2110 | 2060-2450 | 2450-2840 |
| 0.80 | 1710-2060 | 2010-2400 | 2400-2840 |
| 0.90 | 1710-2060 | 2010-2350 | 2350-2750 |
| 1.00 | 1660-2010 | 1960-2300 | 2300-2690 |
| 1.20 | 1620-1960 | 1910-2250 | 2250-2550 |
| 1.40 | 1620-1910 | 1860-2210 | 2150-2450 |
| 1.60 | 1570-1860 | 1810-2160 | 2100-2400 |
| 1.80 | 1520-1810 | 1760-2110 | 2010-2300 |
| 2.00 | 1470-1760 | 1710-2010 | 1910-2200 |
| 2.20 | 1420-1710 | 1660-1960 | 1810-2110 |
| 2.50 | 1420-1710 | 1660-1960 | 1760-2060 |
| 2.80 | 1370-1670 | 1620-1910 | 1710-2010 |
| 3.00 | 1370-1670 | 1570-1860 | 1710-1960 |
| 3.20 | 1320-1620 | 1570-1810 | 1660-1910 |
| 3.50 | 1320-1620 | 1570-1810 | 1660-1910 |
| 4.00 | 1320-1620 | 1570-1760 | 1620-1860 |
| 4.50 | 1320-1570 | 1520-1760 | 1620-1860 |
| 5.00 | 1320-1570 | 1470-1710 | 1570-1810 |
| 5.50 | 1270-1520 | 1470-1710 | 1570-1810 |
| 6.00 | 1220-1470 | 1420-1660 | 1520-1760 |
