| Place of Origin: | Shanghai ,Shanxi |
|---|---|
| Brand Name: | XINFUTIAN |
| Certification: | ISO ,SGS,BV |
| Model Number: | 300 Series 309S |
| Minimum Order Quantity: | 1 ton according to products |
| Price: | Negotiation |
| Packaging Details: | Export Package |
| Delivery Time: | 5-10 working days |
| Payment Terms: | L/C, T/T, D/P, Western Union |
| Supply Ability: | 2000 T/Month |
| Name: | 316 316L Stainless Steel Pipe | Thickness: | 0.1mm-1.2mm |
|---|---|---|---|
| Surface: | BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D | Grade: | 316 316L |
| Technique: | Cold Drawn | Standard: | JIS, AiSi, ASTM, GB, DIN, EN |
| High Light: | 316L erw welded pipe,0.1mm welded steel pipe,316L SS erw pipe |
||
Welded Stainless Steel Steel Pipe 316/316L Tubes standard specification
The Stainless Steel 316/316L Tubes standard specification is ASME SA/ASTM A 213/A269/A249. The size of this grade tube is ranging from 1/8"NB to 30"NB IN. The tubes are in 0.35mm to 6.35mm OD in thickness ranges in 0.1mm to 1.2mm. The schedules of it are like welded, ERW, LSAW, fabricated, seamless etc. The form in which it is available is hydraulic, square, round, rectangle etc. The length in which it is available is single and double random and in cut length. The ends are treaded, plain and beveled ends.
Chemical Composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 - 18.00 | 2.00 - 3.00 | 11.00 - 14.00 | 67.845 min |
| SS 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 - 18.00 | 2.00 - 3.00 | 10.00 - 14.00 | 68.89 min |
Mechanical Properties
| Tensile Strength | Yield Strength (0.2%Offset) | Elongation | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | |||
| Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % | 95 | 217 |
Application:
316 stainless steel pipes are exclusively used in chemical/pharmaceutical, oil and gas, medical, food and drink, water, architectural/civil engineering etc.
FAQ
Q1: Are you a factory or a trade company?
A1: We are a professional manufacturer for designing and producing of Large-size products.
Q2: Do you make customized products or finished parts?
A2: All parts are custom made only, and in stock, we can produce based on your drawings.
Q3: Will my drawing be safe after you get it?
A3: Yes, we will not release your design to third party unless with your permission.
Q4: What is the MOQ?
A4: Small order is acceptable, but the more, the cheaper.
Q5: How about the samples?
A5: We are happy to make prototype part or sample for clients to ensure quality standard, but it’s charged according to your drawing.
