Place of Origin: | Shanghai ,Shanxi |
---|---|
Brand Name: | BAOSTEEL , TISCO ,HONGWANG ,LISCO, |
Certification: | ISO ,SGS,BV |
Model Number: | 300 Series 301 304 316 |
Minimum Order Quantity: | 1 ton according to products |
Price: | Negotiation |
Packaging Details: | Export Package |
Delivery Time: | 5-10 working days |
Payment Terms: | L/C, T/T, D/P, Western Union |
Supply Ability: | 2000 T/Month |
Name: | Stainless Steel Strip Ultra Thin Precision 301 304 316 | Thickness: | 3mm |
---|---|---|---|
Finish: | NO 1,2B | Width: | 6-600MM |
Standard: | JIS/ASTM/BN | Shape: | Coil |
High Light: | Ultrathin 316l coil,Ultrathin Stainless Steel Strip Coil,austenitic 316l coil |
301 304L 316 Ultra Thin Precision Stainless Steel Strip / Stainless Steel Foil Rolls
1. Products Details
304/304L stainless sheet/coil and plate is part of the austenitic family of stainless steel. 304 grades contain a lower level of carbon than 302 and 304L has a lower carbon level than straight grade 304. Types 304 and 304L have very good drawability and excellent corrosion resistance in chemical, textile, petroleum and food industry exposure.
Grade | Temper | HV |
304 | ANN | 200 max |
1/2H | 250 min. | |
3/4H | 310 min. | |
FH | 370 min. | |
301 | ANN | 218 max. |
1/2H | 310 min. | |
3/4H | 370 min. | |
FH | 430 min. | |
EH | 490 min. |
Grade | Cold / Hot Rolled 3mm 304L Stainless Steel Strip Coil |
Thinckness | 0.02-0.05 mm |
Standard | JIS, AISI, ASTM, GB, DIN, EN ,etc. |
Finish | 2B, NO1,Hairline, No.4, BA, 8K mirror, etc. |
Certification | SGS |
Packaging | Standard exporting packing; seaworthy package. |
MOQ | 1 Tons |
Price time | FOB, CFR, CIF, CNF |
Remarks | Insurance is all risks and accept the third party test |
304l | C | Si | Mn | P | S | Ni | Cr |
≤0.03 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 8.00~12.00 | 18.00~20.00 |
Pysical properties
304l | Tensile Strength: | σb (MPa)≥520 |
Yield strength : | σ0.2 (MPa)≥205 | |
Elongation: | δ5 (%)≥40 | |
Hardness : | ≤187HB;≤90HRB;≤200HV | |
Density : | 7.93g/cm3 | |
specific heat capacity | c(20℃)0.502 J·(g·C)-1 | |
heat conductivity | λ/W(m·℃)-1 | |
melting point | 1398~1420℃ | |
304l | Tensile Strength: | σb (MPa)≥520 |
Yield strength : | σ0.2 (MPa)≥205 | |
Elongation: | δ5 (%)≥40 | |
Hardness : | ≤187HB;≤90HRB;≤200HV |
3. Payment And Delivery time
Payment | Payment by T/T, 30% as advance payment and 70% balance pay before shipping. |
Delivery time |
A.7 days if this goods is stock goods. B.20 days if this goods will be produced after order |
Validity | Valid time is 3 days for price usually. |
4. Surface of stainless steel sheet
