Customized Aisi 201 304 316 2b Surface Seamless Welded Stainless Steel Pipe

Basic Information
Place of Origin: Shanghai ,Shanxi
Brand Name: XINFUTIAN
Certification: ISO ,SGS,BV
Model Number: 300 Series 309S
Minimum Order Quantity: 1 ton according to products
Price: Negotiation
Packaging Details: Export Package
Delivery Time: 5-10 working days
Payment Terms: L/C, T/T, D/P, Western Union
Supply Ability: 2000 T/Month
Detail Information
Name: 316 316L Stainless Steel Pipe Thickness: 0.1mm-1.2mm
Surface: BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D Grade: 316 316L
Technique: Cold Drawn Standard: JIS, AiSi, ASTM, GB, DIN, EN
High Light:

2b Surface Welded Stainless Steel Pipe

,

Aisi 201 Welded Stainless Steel Pipe

,

304 stainless steel welded tubes


Product Description

Customized Aisi 201 304 316 2b Surface Seamless Or Welded Stainless Steel Pipe



The Stainless Steel 316/316L Tubes standard specification is ASME SA/ASTM A 213/A269/A249. The size of this grade tube is ranging from 1/8"NB to 30"NB IN. The tubes are in 0.35mm to 6.35mm OD in thickness ranges in 0.1mm to 1.2mm. The schedules of it are like welded, ERW, LSAW, fabricated, seamless etc. The form in which it is available is hydraulic, square, round, rectangle etc. The length in which it is available is single and double random and in cut length. The ends are treaded, plain and beveled ends.



ITEM SS Pipe
BRAND RONSCO,BAOSTEEL, JISCO, TISCO, etc.
MATERIAL 200,300 and 400 SERIES
STANDARD GB, AISI, ASTM, ASME, EN, BS, DIN, JIS
CERTIFICATE CE,BV,SGS
SURFACE black, bright, polished, peeled
THICKNESS 0.4~6.0 mm,Or As Your Requirements.
WIDTH 5*5~150*150 mm
LENGTH Below 6 Meters, Or As Your Requirements
APPLICATION Petrol, Oil and Nature gas,Chemical Industry,Boiler,HeatExchangeArchitecture,Machine Equipment,City Decoration,Bridge, Food and Medical Industry,ElectricComponents,Shipping Manufacture,etc
PACKING Standard export sea-worthy packing
SHIPMENT As required
LEAD TIME 3-15 days after deposit
PAYMENT T/T, L/C, Western union





Stainless steel pipe chemical composition



Grade Chemical Composition %
C Cr Ni Mn P S Mo Si N
1Cr17Mn6Ni5N (201) ≤0.15 16.00-8.00 3.50-5.50 5.50-7.50 ≤0.06 ≤0.03   ≤1.00 ≤0.25
1Cr18Mn8Ni5N (202) ≤0.15 17.0019.00 4.00-6.00 5.50-7.50 ≤0.06 ≤0.03   ≤1.00 ≤0.25

0Cr18Ni9

(304)

≤0.07 17.00-19.00 8.00-10.00 ≤2.00 ≤0.035 ≤0.03   ≤1.0

00Cr18Ni10

(304L)

≤0.03 18.00-20.00 8.00-10.00 ≤2.00 ≤0.035 ≤0.03   ≤1.0
0Cr17Ni12Mo2 (316) ≤0.08 16.00-18.50 10.00-14.00 ≤2.00 ≤0.035 ≤0.03 2.003.00 ≤1.0
0Cr17Ni14Mo2 (316L) ≤0.03 16.00-18.00 12.00-15.00 ≤2.00 ≤0.035 ≤0.030 2.00-3.00 ≤1.0



Stainless steel pipe is a hollow long round steel, which is widely used in petroleum, chemical, medical, food, light industry, mechanical instrumentation and other industrial pipelines and mechanical structural parts. In addition, when the bending and torsion strength are the same, the weight is lighter, so it is also widely used in the manufacture of mechanical parts and engineering structures. It is also often used to produce various conventional weapons, barrels, shells, etc.



FAQ
Q1: Are you a factory or a trade company?
A1: We are a professional manufacturer for designing and producing of Large-size products.



Q2: Do you make customized products or finished parts?
A2: All parts are custom made only, and in stock, we can produce based on your drawings.



Q3: Will my drawing be safe after you get it?
A3: Yes, we will not release your design to third party unless with your permission.



Q4: What is the MOQ?
A4: Small order is acceptable, but the more, the cheaper.


Q5: How about the samples?
A5: We are happy to make prototype part or sample for clients to ensure quality standard, but it’s charged according to your drawing.



Pipe Quality control

Customized Aisi 201 304 316 2b Surface Seamless Welded Stainless Steel Pipe 0
