Astm 1 4 Stainless Steel Plate 201 304 316 321 In Building

Basic Information
Place of Origin: Ningxia ,China
Brand Name: QTX ,Changjiang
Certification: CO .SGS
Model Number: 99.7,99.8,99.99
Minimum Order Quantity: 1ton
Price: negotiation
Packaging Details: Standard export package
Delivery Time: 7-10 natural days
Payment Terms: T/T, D/P, L/C
Supply Ability: 5000ton/month
Detail Information
Name: Stainless Steel Plate Grade: 200 300 400 500 600 Series
Width10-2000mm Or As Request: 10-2000mm Or As Request Length: According To Customer Needs
Application: Building,Construction,Deaoration Type: Plate
Standard: AiSi Surface Finish: 2B BA 2D 2BB No.3 No.4
High Light:

astm 1 4 stainless steel plate

,

201 grade 1 4 stainless steel plate

,

building 304 stainless steel plate


Product Description

SS ASTM 201 304 316 321 Stainless Steel Plate Stainless Steel Sheet

304, 310S, 316, and 321 are different grades of stainless steel plates. Here is a brief description of each grade:

  1. 304 Stainless Steel Plate: This is a versatile stainless steel grade with good corrosion resistance, high-temperature strength, and excellent formability. It is commonly used in various applications, including kitchen equipment, chemical processing, and transportation.

  2. 310S Stainless Steel Plate: This grade has high-temperature resistance and excellent corrosion resistance. It is often used in high-temperature environments such as furnaces, heat treatment equipment, and the manufacturing of heat exchangers.

  3. 316 Stainless Steel Plate: 316 stainless steel has superior corrosion resistance compared to 304 stainless steel, especially in harsh environments. It is commonly used in applications involving corrosive chemicals, coastal areas, and medical equipment.

  4. 321 Stainless Steel Plate: This grade is stabilized with titanium, which prevents carbide precipitation during welding. It offers excellent resistance to high temperatures and is often used in applications such as aircraft exhaust systems, chemical processing equipment, and heat exchangers.

These grades have specific properties that make them suitable for different applications. When selecting a stainless steel plate, it is important to consider factors such as corrosion resistance, strength, temperature resistance, and the specific requirements of your application.



Product Name Stainless steel pipe
Standard ASTM AISI DIN,EN,GB,JIS
Steel Grade 200 Series:201,202
300 Series:301,304,304L,316,316L,316Ti,317L,321,309s,310s
400 Series:409L,410,410s,420j1,420j2,430,444,441,436
Duplex Steel:904L,2205,2507,2101,2520,2304
Outer
Diameter
6-2500mm(as required)
Thickness 0.3mm-150mm (as required)
Length 2000mm/2500mm/3000mm/6000mm/12000mm(as required
Technique Seamless/Welded
Surface No.12B BA 6K 8K Mirror No.4 HL
Tolerance ±1%
Price Terms FOB,CFR,CIF
Grade C Si Mn P S Ni Cr Mo
201 ≤0.15 S0.75 5.5-7.5 ≤0.06 ≤0.03 3.5-5.5 16.0-18.0
202 ≤0.15 S1.0 7.5-10.0 ≤0.06 ≤0.03 4.0-6.0 17.0-19.0
301 ≤0.15 51.0 ≤2.0 ≤0.045 ≤0.03 6.0-8.0 16.0-18.0
302 ≤0.15 S1.0 ≤2.0 ≤0.035 ≤0.03 8.0-10.0 17.0-19.0
304 ≤0.08 S1.0 ≤2.0 ≤0.045 ≤0.03 8.0-10.5 18.0-20.0
304L 50.03 S1.0 ≤2.0 ≤0.035 ≤0.03 9.0-13.0 18.0-20.0
309S ≤0.08 ≤1.0 ≤2.0 ≤0.045 ≤0.03 12.0-15.0 22.0-24.0
310S ≤0.08 S1.5 ≤2.0 ≤0.035 ≤0.03 19.0-22.0 24.0-26.0
316 ≤0.08 ≤1.0 ≤2.0 ≤0.045 ≤0.03 10.0-14.0 16.0-18.0 2.0-3.0
316L ≤0.03 ≤1.0 ≤2.0 ≤0.045 ≤0.03 12.0-15.0 16.0-18.0 2.0-3.0
321 ≤0.08 ≤1.0 ≤2.0 ≤0.035 ≤0.03 9.0-13.0 17.0-19.0
630 ≤0.07 ≤1.0 ≤1.0 ≤0.035 ≤0.03 3.0-5.0 15.5-17.5
631 ≤0.09 ≤1.0 ≤1.0 ≤0.035 ≤0.035 6.50-7.75 16.0-18.0
904L ≤2.0 ≤0.045 ≤1.0 ≤0.035   23.0-28.0 19.0-23.0 4.0-5.0
2205 ≤0.03 ≤1.0 ≤2.0 ≤0.030 ≤0.02 4.5-6.5 22.0-23.0 3.0-3.5
2507 ≤0.03 ≤0.80 ≤1.2 ≤0.035 ≤0.02 6.0-8.0 24.0-26.0 3.0-5.0
2520 ≤0.08 ≤1.5 ≤2.0 ≤0.045 ≤0.03 0.19-0.22 0.24-0.26
410 ≤0.15 ≤1.0 ≤1.0 ≤0.035 ≤0.03   11.5-13.5
430 ≤0.12 ≤0.75 ≤1.0 ≤0.040 ≤0.03 ≤0.60 16.0-18.0

Product Description



Surface Finish Defination Application
2B Those finished,after cold
rolling,by heat treatment,picking
or other equivialent treatment and
lastly by cold rolling to given
appropriate luster
Medical equipment,Food
industry,Construction
material,Kitchen utensils
BA Those processed with bright heat
treatment after cold rolling
Kitchen utensils,Electric
equipment,Building
construction
No.1 The surface finished by heat
treatment and picking or processes
corresponding tjere to after hot
rolling
Chemical tank,pipe
No.4 Those finished by polishing with
No.150 to No.180 abrasives
specified in JIS R 6001
Kitchen utensils,Building
construction,Medical
equipment
HL Those finished polishing so as to
give continuous polishing streaks
by using abrasive of suitable grain
size
Building construction
8K A mirror-like reflective surface by
polishing with finer abrasives over
800 mesh
Reflector,Mirror,Interior-
Exterior decoration




Astm 1 4 Stainless Steel Plate 201 304 316 321 In Building 0

Astm 1 4 Stainless Steel Plate 201 304 316 321 In Building 1Astm 1 4 Stainless Steel Plate 201 304 316 321 In Building 2Astm 1 4 Stainless Steel Plate 201 304 316 321 In Building 3

Astm 1 4 Stainless Steel Plate 201 304 316 321 In Building 4

Astm 1 4 Stainless Steel Plate 201 304 316 321 In Building 5

Cold Rolled Steel Sheet (Thickness:0.3-3mm)
Astm 1 4 Stainless Steel Plate 201 304 316 321 In Building 6Astm 1 4 Stainless Steel Plate 201 304 316 321 In Building 7

Astm 1 4 Stainless Steel Plate 201 304 316 321 In Building 8

Astm 1 4 Stainless Steel Plate 201 304 316 321 In Building 9

Astm 1 4 Stainless Steel Plate 201 304 316 321 In Building 10
Astm 1 4 Stainless Steel Plate 201 304 316 321 In Building 11

Astm 1 4 Stainless Steel Plate 201 304 316 321 In Building 12

Astm 1 4 Stainless Steel Plate 201 304 316 321 In Building 13



FAQ



Q: What is your terms of payment?
A: We usually accept T/T in advance, L/C for large sum. If you prefer other payments terms, please discuss.

Q: What is the terms of delivery?
A: EXW, FOB, CIF

Q: What is the terms of packing?
A: Generally, we pack our goods in bundles or coils with rods or belts, we could also pack the goods as the customers' requirements.

Q: What is your delivery time?
A: For products in stock, we can ship it within 7 days after receiving the deposit.For custom order, production time is 15-30 workdays after received the deposit.

Q: Could you produce according to the samples?
A: Yes, we could customer-made by your samples or technique drawings, we could build the mold and fixtures.

Q: Can I place an sample order and what is your MOQ if I accept your quality?
A: Yes, we can send you samples but you may pay the express fees, our MOQ is 1 ton.

Q: How could you guarantee your products?
A: We accept and support the third-party inspection.We also could issue the warranty to customer to guarantee the quality.

Q: Where is the port of shipment?
A: Ningbo or Shanghai sea port.

Q:How can I get the price of needed product?
A:It's the best way if you can send us the material, size and surface, so we can produce for u to check the quality.If you still have any confusion, just contact us, we would like to be helpful.
