300 Series Hot Rolled Stainless Steel Sheet 304 Thickness 3MM - 120MM DIN 1.4301

Basic Information
Place of Origin: Shanghai ,Shanxi
Brand Name: BAOSTEEL , TISCO ,HONGWANG ,LISCO,
Certification: ISO ,SGS,BV
Model Number: 300 Series 304
Minimum Order Quantity: 1 ton according to products
Price: Negotiation
Packaging Details: Export Package
Delivery Time: 5-10 working days
Payment Terms: L/C, T/T, D/P, Western Union
Supply Ability: 2000 T/Month
Detail Information
Thickness: 3-120mm Finish: NO 1
Width: 1000mm,1219mm,1250mm,1500mm Color: Natural Surface Or As Customized
Model No: 304 Standard: ASTM /JIS/GB
High Light:

stainless steel sheet 2b finish

,

hairline finish stainless steel sheet


Product Description

304 DIN 1.4301 3mm-120mm Thickness NO1 Finish Hot Rolled Stainless Steel Sheet

300 Series stainless steels are classified as austenitic, and are hardenable only by cold working methods. These grades of stainless have chromium (approx. 18 to 30%) and nickel (approx. 6 to 20%) as their major alloying additions. Type 304 is the most widely used alloy of all stainless steels. 300 Series Stainless steel alloys resist corrosion, maintain their strength at high temperatures and are easy to maintain.

304 standards CHINA:06Cr19Ni10 ASTM/ASME: S30400 DIN: 1.4301

1. Products Details


Commodity300 Series 316 Stainless Steel Plate
Grade301,302,304,304L,316,316L,310S,309S,321,301,310
BrandTISCO ,BAOSTEEL,POSCO,JISCO,LISCO
CertificationSGS,BV,IQI,TUV,ISO,etc
Thickness3mm-120mm
Width1000,1219,1250,1500mm, or as your requirements
Length2000,2438,2500,3000,6000mm, or as your requirements
SurfaceNo.1
StandardASTM,AISI,SUS,JIS,EN,DIN,GB, ASME,etc
Delivery5-7 days after confirming the order
MOQ1 Ton according to products

2. Chemical Properties:

C: ≤0.08 ,Si:≤1.0 ,Mn: ≤2.0 ,Cr:18.0~20.0 ,Ni: 8.0~10.0,S: ≤0.03 ,P: ≤0.045

Pysical properties:

Tensile strength σb (MPa

≥ 520


Specific heat capacity(0 ~ 100 ℃, KJ kgK)

0.50


Conditions yield strength

σ0.2 (MPa) ≥ 205


Thermal conductivity (W m. K)

(100 ℃), 16.3 21.5 (500 ℃)


Elongation δ5 (%)

≥40


The linear expansion coefficient k.

(0 ~ 100 ℃), 17.2 (0 ~ 500 ℃) of 18.4


Section shrinkage ψ (%)

≥ 60


Resistivity (20 ℃, 10 Ω m.)

0.73


Hardness

≤ 187HB; ≤ 90HRB; ≤ 200HV


The longitudinal elastic modulus (20 ℃, KN/mm)193
Melting point (℃)

1398 ~ 1454


Specific heat capacity0.50


3. Applications:

Food preparation equipment, especially in chloride environments
Chemical processing, equipment
Laboratory benches and equipment
Rubber, plastics, pulp & paper machinery
Pollution control equipment
Boat fittings, value and pump trim
Heat exchangers
Pharmaceutical and textile industries
Condensers, evaporators and tanks


4. Processing

Mostly Stainless steel sheet cut from stainless steel coil, but according to the  thickness.If thickness is very thick, it will be sheets  directly. Below are some steps of  sheets process.

1. GRINDING
Grinding finish, also called brushed, directional or satin finish. coil or sheet...
2. POLISHING
polished stainless steel sheet uses grinding fluid to polish by polishing equipment on stainless steel ..
3. PVD COLOR COATING
PVD means Physical Vapor Deposition,working in vacuum condiction.....
4. ETCHING
Etching is corrode different kinds of patterns on stainless steel surfaces by chemical methods.
5. EMBOSSING
It is physical rolling on the stainless steel surface, pattern comes from metal roller....

5.  Package


MOQ1 Ton
Price TermFOB CIF CNF
PaymentL/C at sight or 30% TT as deposit
Delivery Time5-10 days after receiving deposit by T/T or L/C.
SampleSamples free and express charges bear by you

Standard export package with Kraft  paper with wooded trays or as required,containers sizes as follows

20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high) about 24-26CBM, 23MTS
40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high) about 54CBM, 27MTS
40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high) about 68CBM, 27MTS

6. RFQ

1. Q: Could you support free sample?
A:Yes.We can supply free samples.But the delivery charges will be covered by our customers.

2. Q: How about the delivery time?
A:Within 15-20days after receiving the deposit or L/C at sight.

3. Q: How about the trade terms?
A:,FOB,CIF will be accepted.

4. Q: How about your payment terms?
A:30%TT in advance and the balance against of copy of B/L.
The irrevocable L/C at sight will be accepted.

5. Q: How many coutries you already exported ?
A:Exported to more than 20 countries mainly from America, Vietnam, UK, Thailand, Egypt, Iran, Turkey, Jordan, etc.


6. Q: How does your company do regarding quality control?
A:BV and SGS certificates, production process followed the ISO 9000 system.
