TISCO ZPSS Cold Rolled Steel Sheet 254SMO Roll 28 / 26 Gauge For Petroleum Production

China TISCO ZPSS Cold Rolled Steel Sheet 254SMO Roll 28 / 26 Gauge For Petroleum Production supplier
TISCO ZPSS Cold Rolled Steel Sheet 254SMO Roll 28 / 26 Gauge For Petroleum Production supplier TISCO ZPSS Cold Rolled Steel Sheet 254SMO Roll 28 / 26 Gauge For Petroleum Production supplier TISCO ZPSS Cold Rolled Steel Sheet 254SMO Roll 28 / 26 Gauge For Petroleum Production supplier TISCO ZPSS Cold Rolled Steel Sheet 254SMO Roll 28 / 26 Gauge For Petroleum Production supplier

Large Image :  TISCO ZPSS Cold Rolled Steel Sheet 254SMO Roll 28 / 26 Gauge For Petroleum Production

Product Details:

Place of Origin: shananxi
Brand Name: TISCO,ZPSS,
Certification: ISO9000 ,SGS,BV,GB
Model Number: 254SMO

Payment & Shipping Terms:

Minimum Order Quantity: 1 ton according to products
Price: Negotiation
Packaging Details: Export Package
Delivery Time: 5-10 working days
Payment Terms: L/C, T/T, D/P, Western Union
Supply Ability: 1000 T/Month
Contact Now
Detailed Product Description
Steel Grade: 254SMO/UNS S31254 Application: Food And Chemical Processing Equipment
Length: 3000mm~6000mm,6 Meters Or Customized Thickness: 0.3mm-6.0mm
Width: 1000,1219,1500mm Surface: NO.3/NO.4/8K/HL/2D/1D, HL, 8K, 2B, BA



Custom Cut Stainless Steel Sheet Stock 254SMO Roll 28 Gauge 26 Gauge



Introduction



Stainless steel grade 254 SMO™ is a very high end austenitic stainless steel. It is designed with a combination of impact toughness resistance to chloride stress corrosion cracking, and pitting and crevice corrosion with strength that is twice that of the stainless steel 300 series.

For certain applications, grade 254 SMO™ has been reported to be a cost-effective substitute for high nickel and titanium alloys. It is known to possess excellent workability as well.



Chemical Composition



Fe Cr Ni Mo C Mn Si P S Cu
balance 19.5 17.5 6.0           0.50
20.5 18.5 6.5 0.020 1.00 0.80 0.030 0.010 1.00



Physical Properties



Properties Metric Imperial
Density 8 g/cm3 0.289 lb/in3



Properties Metric Imperial
Tensile strength 680 MPa 98600 psi
Yield strength 300 MPa 43500 psi
Modulus of elasticity 195 GPa 28300 ksi
Shear modulus 75 GPa 10900 ksi
Poisson’s ratio 0.30 0.30
Elongation at break 50 % 50 %
Hardness, Brinell 210 210



What  other forms we can  offer ?



1.ASTM A240 SMO 254  Perforated Sheet
2.SMO 254 Chequered Plate
3. SMO 254 Rolls

4. SMO 254 Strips
5.SMO 254 Flat



Corrosion resistance



Uniform corrosion The high content of alloying elements gives Ultra 254 SMO exceptionally good resistance to uniform corrosion. It can withstand a wide range of acids due to the high alloying content of chromium and molybdenum. For guidance on material selection in a large number of environments



Applications:



Due to its high levels of molybdenum and nickel, Alloy 254 SMO is frequently used in high chloride environments. Examples of applications that call for the used of Alloy 254 SMO include:



Petroleum production,Desalination equipment,Food and chemical processing equipment,Flue gas desulphurization scrubbers

Saltwater handling,Offshore oil & gas production equipment,Tall oil distillation columns,Pulp mill bleach systems



TISCO ZPSS Cold Rolled Steel Sheet 254SMO Roll 28 / 26 Gauge For Petroleum Production

TISCO ZPSS Cold Rolled Steel Sheet 254SMO Roll 28 / 26 Gauge For Petroleum Production
Others Products we can  supply



TISCO ZPSS Cold Rolled Steel Sheet 254SMO Roll 28 / 26 Gauge For Petroleum Production



Packing and shipping:



1.with wooden pallets, or film covered, in the containers.

2.Export standard package or as the customers' demands.

3.seaworthy wooden cases.

4.with or without edge protector,steel hoop and seals.

5.export -ted standard package or as customers signal requirement.
