| Place of Origin: | shananxi |
|---|---|
| Brand Name: | TISCO,ZPSS， |
| Certification: | ISO9000 ,SGS,BV，GB |
| Model Number: | 254SMO |
| Minimum Order Quantity: | 1 ton according to products |
| Price: | Negotiation |
| Packaging Details: | Export Package |
| Delivery Time: | 5-10 working days |
| Payment Terms: | L/C, T/T, D/P, Western Union |
| Supply Ability: | 1000 T/Month |
| Steel Grade: | 254SMO/UNS S31254 | Application: | Food And Chemical Processing Equipment |
|---|---|---|---|
| Length: | 3000mm~6000mm,6 Meters Or Customized | Thickness: | 0.3mm-6.0mm |
| Width: | 1000,1219,1500mm | Surface: | NO.3/NO.4/8K/HL/2D/1D, HL, 8K, 2B, BA |
| High Light: | cold rolled stainless steel,stainless steel cold rolled sheet |
||
Custom Cut Stainless Steel Sheet Stock 254SMO Roll 28 Gauge 26 Gauge
Introduction
Stainless steel grade 254 SMO™ is a very high end austenitic stainless steel. It is designed with a combination of impact toughness resistance to chloride stress corrosion cracking, and pitting and crevice corrosion with strength that is twice that of the stainless steel 300 series.
For certain applications, grade 254 SMO™ has been reported to be a cost-effective substitute for high nickel and titanium alloys. It is known to possess excellent workability as well.
Chemical Composition
| Fe | Cr | Ni | Mo | C | Mn | Si | P | S | Cu |
| balance | 19.5 | 17.5 | 6.0 | 0.50 | |||||
| 20.5 | 18.5 | 6.5 | 0.020 | 1.00 | 0.80 | 0.030 | 0.010 | 1.00 |
Physical Properties
| Properties | Metric | Imperial |
| Density | 8 g/cm3 | 0.289 lb/in3 |
| Properties | Metric | Imperial |
| Tensile strength | 680 MPa | 98600 psi |
| Yield strength | 300 MPa | 43500 psi |
| Modulus of elasticity | 195 GPa | 28300 ksi |
| Shear modulus | 75 GPa | 10900 ksi |
| Poisson’s ratio | 0.30 | 0.30 |
| Elongation at break | 50 % | 50 % |
| Hardness, Brinell | 210 | 210 |
What other forms we can offer ?
1.ASTM A240 SMO 254 Perforated Sheet
2.SMO 254 Chequered Plate
3. SMO 254 Rolls
4. SMO 254 Strips
5.SMO 254 Flat
Corrosion resistance
Uniform corrosion The high content of alloying elements gives Ultra 254 SMO exceptionally good resistance to uniform corrosion. It can withstand a wide range of acids due to the high alloying content of chromium and molybdenum. For guidance on material selection in a large number of environments
Applications:
Due to its high levels of molybdenum and nickel, Alloy 254 SMO is frequently used in high chloride environments. Examples of applications that call for the used of Alloy 254 SMO include:
Petroleum production,Desalination equipment,Food and chemical processing equipment,Flue gas desulphurization scrubbers
Saltwater handling,Offshore oil & gas production equipment,Tall oil distillation columns,Pulp mill bleach systems
Others Products we can supply
Packing and shipping:
1.with wooden pallets, or film covered, in the containers.
2.Export standard package or as the customers' demands.
3.seaworthy wooden cases.
4.with or without edge protector,steel hoop and seals.
5.export -ted standard package or as customers signal requirement.
