2507 Stainless Steel Pipe Diameter 3.0 - 500mm High Thermal Conductivity

Basic Information
Place of Origin: Shanghai
Brand Name: TISCO ,BAOSTEEL
Certification: ISO,BV
Model Number: 2207/1.4410
Minimum Order Quantity: 2 ton
Price: Negotiation
Packaging Details: Standard Seaworthy package or as the customer's requirement.
Delivery Time: 5-10 working days
Payment Terms: L/C, T/T, Western Union, D/A
Supply Ability: 1000 ton Per Month
Detail Information
Technology: Cold And Hot Rolled Type: Sheet,Rod,Pipe,Coil
Item: Stainless Steel Color: Natural
Shipping: Air,Sea Materials: Duplex Stainless Steel
High Light:

2205 duplex stainless steel

,

duplex 2507 stainless steel


Product Description

Diameter 3.0 - 500mm 2507 1.4410 Duplex Stainless Steel Industrial Pipe

Standards

ASTM/ASME:A240 - UNS S32750
EURONORM:1.4410 - X2 Cr Ni MoN 25.7.4
AFNOR:Z3 CN 25.06 Az
DIN/EN 1.4410,ASME SA-240


Duplex 2507 (UNS S32750) is a super duplex stainless steel with 25% chromium, 4% molybdenum, and 7% nickel designed for demanding applications which require exceptional strength and corrosion resistance, such as chemical process, petrochemical, and seawater equipment. The steel has excellent resistance to chloride stress corrosion cracking, high thermal conductivity, and a low coefficient of thermal expansion. The high chromium, molybdenum, and nickel levels provide excellent resistance to pitting, crevice, and general corrosion.

1.Products Details


WUXI XINFUTIAN METAL PRODUCTS CO., LTD inventory now includes Duplex 2507, which is a super duplex stainless steel with 25% chromium, 4% molybdenum, and 7% nickel. This alloy is designed for applications which require exceptional strength and corrosion resistance; examples include applications in chemical processing, petrochemical, and seawater equipment. The steel has excellent resistance to chloride stress corrosion cracking, high thermal conductivity and a low coefficient of thermal expansion. The high chromium, molybdenum, and nickel levels provide excellent resistance to pitting, crevice, and general corrosion.

Chemical Properties


C Cr Ni Mo N Others
0.020 25 7 4.0 .27 S=0.001


Mechanical Properties


1. 2507 duplex stainless steel pipe mechanical properties at room temperature

Pipe: thickness≤20mm ;δb/MPa:800-1000 ,δ0.2/MPa:≥550 ,δ5/%:≥25 ,(HV):290

2. 2507 duplex stainless steel plate in the mechanical properties of room temperature of -200 ℃ :

/℃ δb/MPa
Room Temperature ≥530
Sheet 100 ≥450
200 ≥400

3. Mechanical properties of 2507 large-diameter seamless tube
Dia*thickness       δb/MPa  δ0.2/MPa   δ5/% (HV)
273.0mm×4.19mm   894      644          40      284
323.9mm×4.57mm   858      662          45       270
406.4mm×4.74mm   854      657          41       272

2. Corrosion

General Corrosion
1). high chromium and molybdenum content of 2507 makes it extremely resistant to uniform corrosion by organic acids like formic and acetic acid.
2). provides excellent resistance to inorganic acids, especially those containing chlorides.
3). can be used in dilute hydrochloric acid.
4). Pitting need not be a risk in the zone below the borderline in this figure, but crevices must be avoided.


Intergranural Corrosion
1). Low carbon content greatly lowers the risk of carbide precipitation at the grain boundaries during heat treatment.
2). Is highly resistant to carbide-related intergranular corrosion.


Stress Corrosion Cracking
1). Duplex structure of 2507 provides excellent resistance to chloride stress corrosion cracking (SCC).
2). Superior to 2205 in corrosion resistance and strength.
3). 2507 is especially useful in offshore oil and gas applications and in wells with either naturally high brine levels or where brine has been injected to enhance recovery.


Pitting Corrosion
1). Different testing methods can be used to establish the pitting resistance of steels in chloride-containing solutions.


Crevice Corrosion
1). Highly resistant to crevice corrosion.

3. Payment ,Shipping


MOQ 1 Ton
Price Term FOB
Payment L/C at sight or 30% TT as deposit
Delivery Time 20-30 days after receiving deposit by T/T or L/C.
Sample Samples free and express charges bear by you


Shipping:


Standard export package with water proof paper, and metal pallet, and angle bar protection, and steel strip or as required

20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high) about 24-26CBM, 23MTS

40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high) about 54CBM, 27MTS

40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high) about 68CBM, 27MTS



2507 Stainless Steel Pipe Diameter 3.0 - 500mm High Thermal Conductivity 0
2507 Stainless Steel Pipe Diameter 3.0 - 500mm High Thermal Conductivity 1


WUXI XINFUTIAN METAL PRODUCTS CO.,LTD is a professional company for Stainless steel products production, processing and sales which has experienced over ten years of development. We are located in WUXI, close to Shanghai (BAO STEEL),Zhangjiagang (ZPSS),Ningbo (BAO XIN),enjoying excellent geographic location and convenient water, land and air transportation.

2507 Stainless Steel Pipe Diameter 3.0 - 500mm High Thermal Conductivity 2

The company has modern professional metal processing machines of which the 90% are imported from Japan and Germany. Such as Water Jet machine,Cold/Hot Rolled production line,laser cutting machine,hailrine machine which can provide cutting ,slitting ,polished ,OEM and ODM service for our clients.



2507 Stainless Steel Pipe Diameter 3.0 - 500mm High Thermal Conductivity 3

Our company presist to the spirit of "Integrity,Pragmatic,High quality,First-class”, providing customers with the most satisfactory service .
