| Place of Origin: | Shanghai |
|---|---|
| Brand Name: | TISCO ,BAOSTEEL |
| Certification: | ISO,BV |
| Model Number: | 2304 |
| Minimum Order Quantity: | 2 ton |
| Price: | Negotiation |
| Packaging Details: | Standard Seaworthy package or as the customer's requirement. |
| Delivery Time: | 5-10 working days |
| Payment Terms: | L/C, T/T, Western Union, D/A |
| Supply Ability: | 1000 Ton /Month |
| Technology: | Cold And Hot Rolled | Type: | Round Bar |
|---|---|---|---|
| Item: | Stainless Steel | Color: | Natural |
| Shipping: | Air,Sea | Grade: | 2304 |
| High Light: | duplex 2304 stainless steel,2205 duplex stainless steel |
||
UNS ASTM Duplex 2304 Stainless Steel Round Bar Bright or Black Finish
Duplex 2304 is a 23% chromium, 4% nickel, molybdenum-free duplex stainless steel whose structure is a balance of ferritic and austenitic. It has general corrosion resistance similar or better than Alloys 304L and 316L but with yield strength nearly double that of austenitic stainless steels. Its duplex microstructure and low nickel and high chromium contents also allows Duplex 2304 to demonstrate improved stress corrosion resistant properties compared to 304 and 316. It is typically suitable for all applications in the -58oF to 572oF (-50oC to 300oC) temperature range and is designed to feature high mechanical strength, good weldability, good corrosion resistance, high resistance to stress corrosion cracking, good machinability, low thermal expansion, good fatigue properties, high thermal conductivity, and easy fabrication.
1. Composition
| Grade |
C |
Cr |
Fe |
Mn |
Si |
S |
P |
Ni |
Cu |
N |
|---|---|---|---|---|---|---|---|---|---|---|
|
Duplex 2304 |
0.03 max |
min: 21.5 max:24.5 |
Bal. |
2.5 max |
1.0 max |
0.03 max |
0.04 max |
min:3.0 max:3.5 |
min:0.05 max: 2.0 |
min: 0.05 max: 2.0 |
|
Grade |
Tensile Strength ksi (MPa) min |
Yield Strength 0.2% offset ksi (MPa) min |
Elongation (% in 50mm) min |
Hardness (Brinell) MAX
|
Hardness (Rockwell B) MAX |
|---|---|---|---|---|---|
| Duplex 2304 |
87 (600) |
58 (400) |
25 |
293
|
31j |
2. Processing
Weldability
Can be successfully welded by TIG manual and automatic, PLASMA, MIG, SMAW, SAW, FCAW
Duplex microstructure renders the alloy less sensitive to hot cracking
Pre-heating and post welding is not required
Filler metal should be a balanced ferrite/austenitic type
Machinability
Exhibits improved machinability properties particularly when considering drilling
Low speeds and high feeds will minimize this alloys tendency to work harden
3. Our Service
Pre-sale Service
1. Sample can be offered.
2. We have full stock,and can deliver pipes on time.
3. OEM and ODM order are welcome, Logo printing or design are available.
4. Good Quality + Factory Price + Quick Response + Reliable Service.
5. We have High efficiency foreign trade team.
6. Experienced in manufacture and offer high quality steel pipes .
After you choose
1. We will count cheapest shipping cost and make invoice to you at once.
2. Check quality piece by piece, the pipes will be sent in 1-2 working day after the payment,
3. Email the tracking No. for you to track the parcels.
4. Applications
Duplex 2304 is generally used in the same applications in which Alloys 304 and 316L are used. Some examples of these applications include:
Chloride containing environments
Welded pipe systems within the Pulp and Paper, Chemical and Petrochemical, and Water Treatment industries
Transportations
Heat exchanger tubes
Architecture, building, construction
Pressure vessels
Caustic solutions, organic acids
Food industry
