High Tensile Strengths Profile Stainless Steel 304 Thickness 4mm - 10mm

Place of Origin Jiangsu
Brand Name XINFUTIAN
Certification ISO
Model Number 200 Series 201
Minimum Order Quantity 1 ton
Price Negotiation
Packaging Details Standard Seaworthy package or as the customer's requirement
Delivery Time 5-10 working days
Payment Terms Western Union, L/C, T/T
Supply Ability 1500 ton Per Month
Product Details
Finish Plckled White Use Industry
Type Equal Material 201
Lenght 6m Application Industry
High Light

stainless steel angle bar

,

stainless steel channel

Leave a Message
Product Description



High Tensile Strengths 304 Stainless Steel Profiles Thickness 4mm - 10mm



AISI 201
UNS S20100
EN 1.4372



Type stainless steel angle
Length 6m or as customer's requirement
Standard JIS, AISI, ASTM, GB, DIN, EN ,etc.
MOQ 1 Ton
Application decoration, industry, etc.
Certificate SGS
Packaging Standard exporting packing
Trade terms FOB,CFR,CIF,CNF
Delivery time Within 10 working days after receiving your deposit
Payment terms 1. 30%T/T in advance, the balance against the B/L copy
  2. 30%T/T in advance, the balance against L/C original at sight



Grade Chemical Composition (%)
  C Si Mn P S Ni Cr Mo
201 ≤0.15 ≤1.00 5.5~7.5 ≤0.060 ≤0.030 3.50~5.50 16.00~18.00



Characteristics and application



Stainless steel Angle according to the stress of the structure of the different needs of various components, also can make members between the joints. Widely used in various building structure and engineering structure, such as the beam, Bridges, transmission tower, lifting transportation machinery, ships, industrial furnace, reaction tower, container frame and warehouse shelves, etc.



201/202/304/321/316 etc Stainless Steel Angle  In Stock And Theoretical Weight Table



Specifications Thickness(mm)
Amm*Bmm 3 4 5 6 7 8 9 10
20*20 0.894 1.13 1.38
25*25 1.13 1.45 1.77 2.06
30*30 1.37 1.77 2.17 2.53
35*35 1.61 2.09 2.97 3.01
40*40 1.85 2.41 3.40 3.49
45*45 2.12 2.76 3.79 4.00
50*50 2.36 3.07 4.58 4.46 5.13 5.76 6.42 7.06.
60*60     5.03 5.42 6.24 7.03
63*63     5.42 5.95 6.84 7.71 8.60 9.48
70*70     5.82 6.42 7.39 8.34 9.31 10.3
75*75       6.89 7.95 8.97 10.0 11.1
80*80       7.37 8.50 9.61 10.7 11.8



Packaging & shipping:



Standard export package with water proof paper, and metal pallet, and angle bar protection, and steel strip or as required



20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high) about 24-26CBM, 23MTS

40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high) about 54CBM, 27MTS

40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high) about 68CBM, 27MTS
