Large - Diameter Brushed Stainless Steel Welded Pipe 316 Wall Thickness

Place of Origin WUXI,WENZHOU
Brand Name XINFUTIAN
Certification BV,SGS
Model Number 316l,304
Minimum Order Quantity 1 ton
Price Negotiation
Packaging Details Plastic bags
Delivery Time 5-7 working days
Payment Terms D/A, L/C, T/T
Supply Ability 1000 ton/Month
Product Details
Type Welded Thickness 0.4-30mm,0.5-100mm,0.25-2.5mm,1mm-40mm,0.8--2mm
Length 6 Meters Or According To Customer's Request Technique Cold Rolled Hot Rolled
Material 200 Series/300 Series/400series Certification ISO, SGS, BV, CE, ISO / SGS
Shape Round Section, Slot, Round / Square / Rectangular / Oval Etc
High Light

stainless steel rectangular tubing

,

duplex stainless steel pipe

Leave a Message
Product Description



Large Diameter Welded Brushed Stainless Steel Pipe 316 Wall Thickness



The 300 series stainless steels are classified as austenitic and are hardenable only by cold working methods. These grades of stainless have approximately 18% to 30% chromium and 6% to 20% nickel as their major alloying additions. This series of stainless steel alloys are known to resist corrosion while maintaining their strength at high temperatures. While the 304 grade is the most widely used alloy of all stainless steels, the 300 series grades are inventoried in stainless steel plate, sheet, bar, pipe, tube and fittings and much more.

Size of Stainless steel pipe



Normal Pipe Size
Outside Diameter

Normal Wall Thickness
NPS
DN
OD

SCH10s
SCH40s
STD
SCH40
XS
SCH80s
1/8
6
10.3
-
1.24
1.73
1.73
1.73
2.41
2.41
1/4
8
13.7
-
1.65
2.24
2.24
2.24
3.02
3.02
3/8
10
17.1
-
1.65
2.31
2.31
2.31
3.2
3.2
1/2
15
21.3
1.65
2.11
2.77
2.77
2.77
3.73
3.73
3/4
20
26.7
1.65
2.11
2.87
2.87
2.87
3.91
3.91
1
25
33.4
1.65
2.77
3.38
3.38
3.38
4.55
4.55
1 1/4
32
42.2
1.65
2.77
3.53
3.53
3.53
4.85
4.85
1 1/2
40
48.3
1.65
2.77
3.68
3.68
3.68
5.08
5.08
2
50
60.3
1.65
2.77
3.91
3.91
3.91
5.54
5.54
2 1/2
65
73
2.11
3.05
5.16
5.16
5.16
7.01
7.01
3
80
88.9
2.11
3.05
5.49
5.49
5.49
7.62
7.62
3 1/2
90
101.6
2.11
3.05
5.74
5.74
5.74
8.08
8.08
4
100
114.3
2.11
3.05
6.02
6.02
6.02
8.56
8.56
5
125
141.3
2.77
3.4
6.55
6.55
6.55
9.53
9.53
6
150
168.3
2.77
3.4
7.11
7.11
7.11
10.97
10.97

316 stainless steel pipe is a kind of hollow long round steel, which is widely used in petroleum, chemical industry, medical treatment, food, light industry, mechanical instrument and other industrial transportation pipes and mechanical structural components. In addition, bending, torsional strength of the same weight, so it is also widely used in the manufacture of mechanical parts and engineering structures. Also commonly used for the production of conventional weapons, barrels, shells, etc.


1. Grade:TP304 TP304L TP316L TP317L TP310S 904L 2205 2507

2. Size:19-720MM

3. Standard: ASTM A312 ASTM A213 ASTM A269

4. Certification: ISO9001, SGS



Product Name
Stainless Steel welded  Pipes
Standard
ASTM A312 ASTM A213 ASTM A269
Material
Stainless Steel
Grade
TP304 TP304L TP316LTP316 Ti TP317L TP310S 904L 2205 2507
Size
19-720MM
Brande
"DONGFENG"
Technology
Hot rolling or Cold drawing
Used
Petroleurn/Chemical /Natgas/Building



Large - Diameter Brushed Stainless Steel Welded Pipe 316 Wall Thickness 0

Package

Large - Diameter Brushed Stainless Steel Welded Pipe 316 Wall Thickness 1

Large - Diameter Brushed Stainless Steel Welded Pipe 316 Wall Thickness 2
