Heat Exchanger Seamless Stainless Steel Pipe Excellent Corrosion Resistance

Place of Origin Shanxi
Brand Name LISCO,East SPECIAL
Certification ISO,BV
Model Number Inconel 625
Minimum Order Quantity 1 ton
Price Negotiation
Packaging Details Standard Seaworthy package or as the customer's requirement.
Delivery Time 10 working days
Payment Terms L/C, T/T, D/A
Supply Ability 1000 TON/Month
Product Details
Name Seamless Stainless Steel Pipe Technology Cold And Hot Rolled
Type Seamless, Welded, Round Pipe / Tube Color Natural Color
Feature Excellent Corrosion Resistance
High Light

seamless stainless steel tubing

,

ss 304 seamless pipe

Leave a Message
Product Description

Heat Exchanger Seamless Stainless Steel Pipe Excellent Corrosion Resistance


Seamless Stainless Steel Pipe Introduction


Inconel 625 has excellent strength at temperatures up to 816℃. At higher temperatures, its strength is generally lower than that of other solid solution strengthened alloys. Inconel 625 has good oxidation resistance at temperatures up to 980℃ and shows good resistance to aqueous corrosion, but is relatively moderate compared to other more capable corrosion resistant alloys.



Designation:Inconel 625
Products Category:Inconel Series
Products description:
Equivalent designations
UNS N06625
DIN W. Nr. 2.4856



Form ASTM
Rod and bar B 446
Plate, sheet and strip B 443, B 906
Seamless pipe and tube B 444, B 829
Welded pipe B 705, B 775
Welded tube B 704, B 751
Welding fitting B 366
Billet and bar for reforging B 472
Forging B 564



Chemical composition



% Ni Cr Mo Fe C Mn Si P S Co Nb+Ta Al Ti
min 58.0 20.0 8.0               3.15
max   23.0 10.0 5.0 0.10 0.50 0.50 0.015 0.015 1.00 4.15 0.40 0.40



Seamless Stainless Steel Pipe applications



Even though researchers initially touted its creep strength at high temperatures, it was also shown that alloy 625 could remain nearly corrosion free at ambient to low temperature elevations, like seawater environments or chemical processing of acids and salts. Marine heat exchangers commonly use 625, to isolate corrosive seawater to materials that can endure them, such as 625 based plate and shell and tube heat exchangers.



It is nearly immune to chloride-ion induced stress cracking, by virtue of its high nickel content, and has been used in propellers and propulsion systems as well as wires used in cable sheathing in marine environments. In addition to saltwater corrosion resistance, the high ductility of 625 makes it ideal for fasteners like hex bolts in underwater environments.


Physical Properties
Density: 0.303 lb/in3 (8.44 g/cm3
Specific Gravity: 8.44
Melting Range: 2350 - 2460°F (1280 - 1350°C)
Specific Heat: 0.098 Btu/lb x °F (410 Joules/kg x °K)
Magnetic Permeability (75°F, 200 oersted): 1.0006




Our Services

· We ues the first grade material in China.”Quality is our culture”


· Good Services, adhere to the principle of customer first .


· Any special size can be customed ,and the price can be discussed.


· Good package, Pallets with waterproof or as customers' demands .


· Laser cutting, Water cutting and High accuracy are available.


· Surface finished: 2B, BA, mirror (8K), HL .


· Delivery fast , 5-7 working days after receiving the 30% deposit (at warehourse)


· Your problem is our probem.
