High Temperature Strength Seamless Tube Stainless Steel , 2520 Seamless Ss Pipe

Place of Origin Wuxi
Brand Name XINFUTIAN
Certification ISO ,SGS,BV
Model Number 2520
Minimum Order Quantity 1 ton according to products
Price Negotiation
Packaging Details Export Package
Delivery Time 5-10 working days
Payment Terms L/C, T/T, D/P, Western Union
Supply Ability 2000 T/Month
Product Details
Name Seamless Tube Stainless Steel Steel Grade 2520
Type Seamless Feature High Temperature Strength
Standard ASTM,AISI,GB,DIN,JIS Thickness 0.4-30mm
High Light

seamless stainless steel tubing

,

ss 304 seamless pipe

Leave a Message
Product Description

High Temperature Strength Seamless Tube Stainless Steel , 2520 Seamless Ss Pipe



1. Type of 2520 stainless steel grade



2520 stainless steel is an abbreviation for China's stainless steel standard.

2520 Chinese Standard

Old grade: 0Cr25Ni20 (GB/T3280-1992)

New grade: 06Cr25Ni20 (GB/T20878-2007)

China Uniform Digital Code: S31008 (GB/T20878-2007)



2. The main properties of 2520 stainless steel



Due to high content of nickel (Ni) and chromium (Cr), it has good oxidation resistance, corrosion resistance, acid and alkali resistance and high temperature resistance. High temperature resistant steel tubes are specially used for the manufacture of electric heating tubes, etc., and carbon is added to austenitic stainless steel. After the content, the strength is improved by the solid solution strengthening effect. The chemical composition of the austenitic stainless steel is based on chromium, nickel and other elements such as molybdenum, tungsten, niobium and titanium. Since the structure is a face-centered cubic structure, Thus there is high strength and creep strength at high temperatures. 2520 stainless steel material has 2520 stainless steel plate, 2520 stainless steel rod, 2520 stainless steel tube, 2520 stainless steel angle steel, 2520 stainless steel flat steel, round steel, stainless steel plate, stainless steel rod, stainless steel tube, which can work at a high temperature of 1250 degrees for a long time.



3. Physicochemical properties and mechanical properties of 2520 stainless steel



1. Physical and chemical properties

It has high high temperature strength and oxidation resistance, and is sensitive to sulfur-containing atmosphere. It has a brittle tendency of precipitated phase at 600-800 °C, and is suitable for making various furnace components subjected to stress.

2, mechanical properties

Tensile strength σb (MPa): ≥ 590 Conditional yield strength σ0.2 (MPa): ≥ 295 elongation δ 5 (%): ≥ 35 section shrinkage ψ (%): ≥ 50 hardness: ≤ 187H



  C Si Mn P S Cr Ni
standard £0.08 £1.50 £2.00 £0.045 £0.030 24.00~26.00 19.00~22.00
normal 0.05 0.51 1.3 0.020 0.001 25.5 19.6





Grade:

201, 202 , 304 , 304L , 304H , 309, 309S , 310 , 310S ,316, 316L, 316Ti, 317, 317L, 321, 347, 347H , 409L , 420 , 420J1 , 420J2 , 430 , 431,434 , 436L , 439 , 441, 443 , 444 , 904L , 2205 , 2507 , 253MA , 254Mo , 631 , 654MO ,17-4pH ,N08367 (AL 6XN ) ,etc.
Thickness: 0.05mm-60mm
Length: 2000mm to 6000mm or as your required(Customized)
Surface: 2B, No.1, No. 4, No.8, BA, 6K, 1D, 2D, Mirror Finished, 8K, Hair Line with PVC
Size: standard size or according to your requirement
Payment Terms: T/T, L/C at sight
Packing: Standard export packing (According to customer's requests)
Technique: Cold rolled/hot rolled
Shipment: By sea, by air, by express(Shipment can be made within 7-10 days.)
Origin: TISCO, ZPSS, Baosteel, JISCO, ZSESS, ATI, SMC, HAYNES, VDM, ArcelorMittal, Outokumpo, etc.







Standard:

ASME, ASTM, EN, BS, GB, DIN, JIS, etc
EN Standard:
Austenitic: 1.4372 ,1.4373, 1.4310, 1.4305, 1.4301, 1.4306 , 1.4318 ,1.4335, 1.4833 , 1.4835 , 1.4845, 1.4841, 1.4401 , 1.4404 , 1.4571 ,1.4438, 1.4541 , 1.4878 , 1.4550 , 1.4539 , 1.4563 , 1.4547
Duplex: 1.4462 , 1.4362 ,1.4410 , 1.4507
Ferritic :1.4512, 1.400 , 1.4016 ,1.4113 , 1.4526 ,1.4521 , 1.4530 , 1.4749 ,1.4057;
Martensitic: 1.4006 , 1.4021 ,1.4418 ,S165M ,S135M;
