Place of Origin: | Jiangsu |
---|---|
Brand Name: | XINFUTIAN |
Certification: | ISO,BV |
Model Number: | 65#,70#,82b high carbon spring wire |
Minimum Order Quantity: | 5 ton |
Price: | Negotiation |
Packaging Details: | Standard Seaworthy package or as the customer's requirement |
Delivery Time: | 5-10 working days |
Supply Ability: | 1000 Ton Per Month |
Product Name: | Low Carbon Stee Wire | Tolerance: | ±1% |
---|---|---|---|
Coil Weight: | 200-1200kgs | Type: | Galvanized |
Surface Treatment: | Customized | Special Use: | Cold Heading Steel |
High Light: | 1200kgs galvanized steel wire,1200kgs 50# steel wire,0.3mm galvanized steel wire |
45# 50# 65# Low High Carbon Spring Wire Galvanized Steel Wire
PRODUCTS DESCRIPTION:
1. Material:45#,50#,65#,70#
2. Surface Coating: uncoated
3. Characteristic: Patented cold drawn unalloyed steel wire of circular cross-section
High tensile strength,strict tolerance
The wire must be free from contamination,rust and mechanical damage
4. Packing type: Coil Packing, Z2 Packing
5. Application: Mainly used for mattress, car cushion, bicyle springs etc
6. Remarks during use and handling:
a. During transportation, handle softly and carefully, avoid bumping and damaging the steel wires. Moisture and rain prohibited. Steel wires must be stored in dry warehouse
b. Pay attention to the direction of steel wires when paying-off. Be sure the spools or coilis rotationg freely as to achieve identical tension of all the steel wires
c. If the single unit package can not be used up,the remained wire should be repacked to avoid oxidizing.
Technical parameters:
Diameter mm |
Deviation mm |
Tensile strength MPa | ||
B Grade | C Grade | D Grade | ||
0.30 | ±0.014 | 2010-2400 | 2300-2700 | 2640-3040 |
0.32 | ±0.018 | 1960-2350 | 2250-2650 | 2600-2990 |
0.35 | 1960-2350 | 2250-2650 | 2600-2990 | |
0.40 | 1910-2300 | 2250-2650 | 2600-2990 | |
0.45 | 1860-2260 | 2200-2600 | 2550-2940 | |
0.50 | 1860-2260 | 2200-2600 | 2550-2940 | |
0.55 | 1810-2210 | 2150-2550 | 2500-2890 | |
0.60 | 1760-2160 | 2110-2500 | 2450-2840 | |
0.65 | ±0.02 | 1760-2160 | 2110-2500 | 2450-2840 |
0.70 | 1710-2110 | 2060-2450 | 2450-2840 | |
0.80 | 1710-2060 | 2010-2400 | 2400-2840 | |
0.90 | 1710-2060 | 2010-2350 | 2350-2750 | |
1.00 | 1660-2010 | 1960-2300 | 2300-2690 | |
1.20 | ±0.03 | 1620-1960 | 1910-2250 | 2250-2550 |
1.40 | 1620-1910 | 1860-2210 | 2150-2450 | |
1.60 | 1570-1860 | 1810-2160 | 2110-2400 | |
1.80 | 1520-1810 | 1760-2110 | 2010-2300 | |
2.00 | 1470-1760 | 1710-2010 | 1910-2200 | |
2.20 | 1420-1710 | 1660-1960 | 1810-2110 | |
2.50 | 1420-1710 | 1660-1960 | 1760-2060 | |
2.80 | 1370-1670 | 1620-1910 | 1710-2010 | |
3.00 | 1370-1670 | 1570-1860 | 1710-1960 | |
3.20 | ±0.038 | 1320-1620 | 1570-1810 | 1660-1910 |
3.50 | 1320-1620 | 1570-1810 | 1660-1910 | |
4.00 | 1320-1620 | 1520-1760 | 1620-1860 | |
4.50 | 1320-1570 | 1520-1760 | 1620-1860 | |
5.00 | 1320-1570 | 1470-1710 | 1570-1810 | |
5.50 | 1270-1520 | 1470-1710 | 1570-1810 | |
6.00 | 1220-1470 | 1420-1660 | 1520-1760 |
