Certification: | ISO,BV,CE | Application: | Sanitory ,Food Industry |
---|---|---|---|
Steel Grade: | 300 Series,200 Series,400 Series | Standard: | ASTM,JIS,AISI,DIN,EN |
Welding Line Type: | Round Square | Product Name: | 321 Sanitory Grade Welded Pipe |
Type: | Welded, Seamless, Liquefied Petroleum Gas, Round Pipe / Tube, Welded | ||
High Light: | Mirror 321 stainless steel pipe,SGS 321 stainless steel pipe,BV 321 stainless steel tube |
SS 316 Stainless Steel Tube/ASTM 304 201 stainless steel Pipe DN100 150 SCH40
Product Name | Round pipe for decorative Bright mirror color stainless steel pipe |
Standard | ASTM A554, A249, A269 and A270, A312,EN10296-2 |
Round Pipe Size | 8-219mm |
Square Pipe Size | 10x10-100x100 |
Rectangular Pipe Size | 10X20,60x120 |
Thickness | 0.6mm-3mm |
Thickness Tolerance | +/-10% |
Length Tolerance | +/-8mm |
OD Tolerance | According to ASTM A554 standard |
Surface | 180G, 320G, 400G Satin / Hairline, 400G, 500G, 600G or 800G Mirror finish, Bright |
What is the whole process for doing business with us ?
1) Please provide details products information you need.
2) If price acceptable and sample needed, sample can be customized via customers' requirement and be sent immediately.
3) If sample approved and bulk production required for order,proforma Invoice will be sent and products fabricating will be arranged at once when 30% deposit received.
4) Products photos, packing details, and will be sent to customers after products finished. Shipment will be arranged after the balance payment paid.
Available Sizes
OD (mm) |
Thickness (mm) | ||||||||||
0.5 | 0.6 | 0.7 | 0.8 | 1.0 | 1.2 | 1.5 | 2.0 | 2.5 | 3.0 | 4.0 | |
12.7 | √ | √ | √ | √ | √ | √ | √ | ||||
15.9 | √ | √ | √ | √ | √ | √ | √ | ||||
19.0 | √ | √ | √ | √ | √ | √ | √ | √ | |||
22.2 | √ | √ | √ | √ | √ | √ | √ | √ | |||
25.4 | √ | √ | √ | √ | √ | √ | √ | √ | |||
28.5 | √ | √ | √ | √ | √ | √ | √ | √ | |||
31.8 | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | |
34.0 | √ | √ | √ | √ | |||||||
38.1 | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | |
41.3 | √ | √ | √ | √ | √ | √ | |||||
42.7 | √ | √ | √ | √ | |||||||
45.0 | √ | √ | √ | √ | √ | ||||||
48.6 | √ | √ | √ | √ | |||||||
50.8 | √ | √ | √ | √ | √ | √ | √ | ||||
57.0 | √ | √ | √ | √ | √ | √ | |||||
63.5 | √ | √ | √ | √ | √ | √ | √ | ||||
76.2 | √ | √ | √ | √ | √ | √ | √ | ||||
88.9 | √ | √ | √ | √ | √ | √ | √ | ||||
101.6 | √ | √ | √ | √ | √ | ||||||
108.0 | √ | √ | √ | √ | √ | ||||||
114.3 | √ | √ | √ | √ | √ | ||||||
127.0 | √ | √ | √ | √ | |||||||
133.0 | √ | √ | √ | √ | |||||||
159.0 | √ | √ | √ | √ |
