Place of Origin: | Shanghai ,Shanxi |
---|---|
Brand Name: | HONGWANG ,LISCO |
Certification: | ISO ,SGS,BV |
Model Number: | 300 Series 316L |
Minimum Order Quantity: | 1 ton according to products |
Price: | Negotiation |
Packaging Details: | Export Package |
Delivery Time: | 5-10 working days |
Payment Terms: | L/C, T/T, D/P, Western Union |
Supply Ability: | 2000 ton/ Month |
Thickness: | 0.3-25mm | Finish: | 2B ,Hairilne,BA,NO6,N0 8 |
---|---|---|---|
Width: | 1000mm,1219mm,1250mm,1500mm | Color: | Natural Surface Or As Customized |
Market: | USA ,the Middle East,South Africa | Length: | 2500mm.6000mm |
Highlight: | 20 Gauge 316 stainless sheet,20 Gauge 316 stainless plate,3mm 316 stainless steel sheet |
Food Grade Cold Rolled 316 Stainless Steel Sheet Thickness 16,,18,20 Gauge
Fabrication
Fabrication of all stainless steels should be done only with tools dedicated to stainless steel materials. Tooling and work surfaces must be thoroughly cleaned before use. These precautions are necessary to avoid cross contamination of stainless steel by easily corroded metals that may discolour the surface of the fabricated product.
Cold Working
Grade 316 is readily brake or roll formed into a variety of parts. It is also suited to stamping, heading and drawing but post work annealing is recommended to relieve internal stresses.
Cold working will increase both strength and hardness of 316 stainless steel.
Products Details
Commodity | 300 Series 316 Stainless Steel Plate |
Grade | 301,302,304,304L,316,316L,310S,309S,321,301,310 |
Brand | TISCO ,BAOSTEEL,POSCO,JISCO,LISCO |
Certification | SGS,BV,IQI,TUV,ISO,etc |
Thickness | 0.3mm-25mm |
Width | 1000,1219,1250,1500mm, or as your requirements |
Length | 2000,2438,2500,3000,6000mm, or as your requirements |
Surface | No.1, 2B, BA, 8K Mirror, Hairline,satin, Embossed,brush,No.4,HL,matt,pvc film,laser film. |
Standard | ASTM,AISI,SUS,JIS,EN,DIN,GB, ASME,etc |
Delivery | 5-7 days after confirming the order |
MOQ | 1 Ton |
Chemical Properties:
C | Mn | Si | P | S | Cr | Mo | Ni | N | |
316L (S31603) |
0.03 max |
2.0 max |
0.75 max |
0.045 max |
0.03 max |
min: 16.0 max: 18.0 |
min: 2.0 max: 3.0 |
min: 10.0 max: 14.0 |
0.10 max |
Grade | Tensile Strength ksi (min) |
Yield Strength 0.2% ksi (min) |
Elongation % | Hardness (Brinell) MAX | Hardness (Rockwell B) MAX |
316L (S31603) |
70 | 25 | 40 | 217 | 95 |
Package
MOQ | 1 Ton |
Price Term | FOB CIF CNF |
Payment | L/C at sight or 30% TT as deposit |
Delivery Time | 5-10 days after receiving deposit by T/T or L/C. |
Sample | Samples free and express charges bear by you |
Standard export package with Kraft paper with wooded trays or as required,containers sizes as follows
20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high) about 24-26CBM, 23MTS
40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high) about 54CBM, 27MTS
40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high) about 68CBM, 27MTS
Features of stainless steel sheet:
· They have a High strength which helps them to withstand in high temperature
· These sheets exhibit excellent corrosion resistance
· High toughness and impact resistance
· The sheets are Temperature resistance to high heat
· They have excellent workability including stamping, welding, machining and fabricating
· These sheets have a smooth surface finish that can be easily sterilized and cleaned
