| Place of Origin: | Shanghai ,Shanxi |
|---|---|
| Brand Name: | BAOSTEEL , TISCO ,HONGWANG ,LISCO， |
| Certification: | ISO ,SGS,BV |
| Model Number: | T1 T2 T3 |
| Minimum Order Quantity: | 1 ton according to products |
| Packaging Details: | Standard Seaworthy Packing or as request |
| Delivery Time: | 5-8 working days |
| Supply Ability: | 5000ton/month |
| Name: | Copper Coil Strip | Model Number: | T1 T2 T3 |
|---|---|---|---|
| Shape: | Strip Coil Roll | Grade: | Pure Copper |
| Alloy Or Not: | Non-Alloy | Material: | 99.995% Pure Copper |
| Cu (Min): | 99.90% | Hardness: | 1/2 Hard/1/4Hard/ Hard |
| High Light: | TU0 pure copper strip coil,99.9% pure copper coil strip,Non Alloy pure copper coil strip |
||
T1 T2 T3 TU0 pure copper strip 99.9% copper coil
T 1, T 2 and T 3 are three grades of red copper. What are the differences among these three grades of red copper? The following are the main aspects:
1. Different copper content.
T 1 is the highest and purest pure copper, t 1 chemical composition: Cu + Ag Cuag: ≥99.95.
T2 copper refers to the copper-silver alloy, in which the copper + silver element content of copper can be more than 99.9% , namely, silver + copper + silver CuAq: 2999, there is no requirement for phosphorus.
The content of copper in T 3 is Cu + Ag cuag; ≥99.70.
2. The tensile strength of T1 pure copper with different strength: OB (MPa)≥295, elongation after breaking: 45% ~ 50% HBS: 35 ~ 40. The tensile strength of T 2 copper is AB (Mpa) & GT. 195, and the extension length is 45% ~ 50% HBS: 35 ~ 40. Tensile strength of T 3 Copper AB (MPal: & Gt. 210. Elongation after fracture: 45% ~ 50% HBS: 35 ~ 40. Tensile strength of T 4 copper is lower
3. T1 copper has good middle conductivity, heat conductivity, corrosion resistance and processability. It can be jointed and brazed. There are few impurities which reduce the conductivity and thermal conductivity, and little oxygen has little effect on the performance of conductivity, thermal conductivity and processing. T2 copper has good electrical conductivity, thermal conductivity, corrosion resistance and processability, can be welded and brazed. There are few impurities with lower conductivity and thermal conductivity, and trace oxygen has little effect on the properties of conductivity, heat conduction and processing, but it is easy to cause"Hydrogen disease". The content of copper in T 3 is lower than that in T 2. The content of copper in T 3 is higher than that in T 2.
|
Item
|
High Quality 99.99% C11000 Copper Coil / Copper foil Strip for Electronics |
| Standard | ASTM B194 ASTM B569 JIS H3130 JIS3100 JIS3110 GB/T 2059 GB/T 2061 |
| Material |
C10100,C10200,C10300,C10400,C10500,C10700,C10800,C10910,C10920,C10930, C11000,C11300,C11400,C11500,C11600,C12000,C12200,C12300,C12500,C14200, C14420,C14500,C14510,C14520,C14530,C17200,C19200,C21000,C23000,C26000, C27000,C27400,C28000,C33000,C33200,C37000,C44300,C44400,C44500,C60800, C63020,C65500,C68700,C70400,C70620,C71000,C71500,C71520,C71640,C72200,etc |
| Width | 30-1000mm |
| Thickness | 0.1-3.0mm |
| Hardness | 1/4 hard,1/2hard,full hard,soft,etc. |
| Surface | mill,polished,film-coated |
| Price Term | Ex-Work,FOB,CNF,CFR,CIF,FCA, etc |
| Payment Term | TT,D/P,L/C,Western Union,etc |
| Export to |
Singapore,Indonesia,Ukraine,Korea,Thailand,Viet Nam,Saudi Arabia,Brazil,Spain,Canada,USA,Kuwait,Dubai,Oman,Kuwait,Peru,Mexico,Iraq,Russia, Malaysia,etc |
| MOQ | 1 Ton |
| Package | Standard export package or as required. |
