| Place of Origin: | Shanghai ,Shanxi |
|---|---|
| Brand Name: | BAOSTEEL , TISCO ,HONGWANG ,LISCO |
| Certification: | ISO ,SGS,BV |
| Model Number: | 300 Series 316 |
| Minimum Order Quantity: | 1 ton according to products |
| Price: | Negotiation |
| Packaging Details: | Export Package |
| Delivery Time: | 5-10 working days |
| Payment Terms: | L/C, T/T, D/P, Western Union |
| Supply Ability: | 2000 ton/Month |
| Thickness: | 0.3-25mm | Finish: | 2B ,Hairilne,BA,NO6,N0 8 |
|---|---|---|---|
| Width: | 1000mm,1219mm,1250mm,1500mm | Color: | Natural Surface Or As Customized |
| Market: | USA ,the Middle East,South Africa | Length: | 2500mm.6000mm |
| High Light: | 316 stainless steel plate,316 stainless steel sheet metal |
||
DIN 1.4401 Stainless Steel Sheet 316 / Grade 316 Stainless Steel Building Material
Products Details
| Commodity | 316 Stainless Steel Sheet |
| Grade | 316L,310S,309S,321,301,304,304L,316, |
| Brand | TISCO ,BAOSTEEL,POSCO,JISCO,LISCO |
| Certification | SGS,BV,IQI,TUV,ISO,etc |
| Thickness | 0.3mm-25mm |
| Width | 1000,1219,1250,1500mm, or as your requirements |
| Length | 2000,2438,2500,3000,6000mm, or as your requirements |
| Surface | No.1, 2B, BA, 8K Mirror, Hairline,satin, |
| Standard | ASTM,AISI,SUS,JIS |
| Delivery | 5-7 days after confirming the order |
| MOQ | 1 Ton |
316 standards
CHINA:06Cr17Ni12Mo2
ASTM/ASME: UNS S31600
AFNOR: Z 6 CND 17-11
DIN: 1.4401
| C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 316 (S31600) | 0.08 max | 2.0 max | 0.75 max | 0.045 max | 0.03 max | min: 16.0 max: 18.0 | min: 2.0 max: 3.0 | min: 10.0 max: 14.0 | 0.10 max |
| 316L (S31603) | 0.03 max | 2.0 max | 0.75 max | 0.045 max | 0.03 max | min: 16.0 max: 18.0 | min: 2.0 max: 3.0 | min: 10.0 max: 14.0 | 0.10 max |
| Grade | Tensile Strength ksi (min) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Brinell) MAX | Hardness (Rockwell B) MAX |
| 316 (S31600) | 75 | 30 | 40 | 217 | 95 |
| 316L (S31603) | 70 | 25 | 40 | 217 | 95 |
Equirements for Stainless Steel Surface Finish
1. No. 1 Finished by hot-rolling, annealing and pickling, characterized by white pickled surface
2. 2B Finished by heat treatment, pickling after cold rolling, followed by skin pass line to be more brighter and smooth surface
3. BA Bright heat treatment after cold rolling
4. No. 4 Polishing with No. 150 to No.180 mesh abrasivesThe most popular finishes
5. HL Finished by continuous linear polishing
