| Place of Origin: | NINGBO CHINA |
|---|---|
| Brand Name: | TISCO, BAOSTEEL, JISCO, ZPSS |
| Certification: | MTC BV SGS ISO |
| Model Number: | 316 316l Stainless Steel Sheet |
| Minimum Order Quantity: | 1 TON |
| Price: | Negotiation |
| Packaging Details: | Standard Seaworthy package or as the customer's requirement |
| Delivery Time: | 7-15 Working days |
| Payment Terms: | T/T L/C at sight |
| Supply Ability: | 1000 Ton per Month |
| Material: | 316 Stainless Steel Sheet | Color: | Bright 2B Finshed |
|---|---|---|---|
| Surface: | 2B BA No.4 6k 8k Hairline Embossed Etched, | Size: | 4(1219MM)X8 (2438MM) Or As Request |
| Type: | Sheet,plate | Technology: | Clod Rolled |
| High Light: | 316 stainless steel plate,316l stainless steel plate |
||
Laser Cutting Customized BA Finish316 316L 316Ti Stainless Steel Sheet
Type 316L is a variant of Type 316 and differs by having a lower Carbon content as well as slightly lower yield and tensile strengths. Type 316L offers improved weldability and also reduces the possibility of lower corrosion resistance around welded areas.
1. Products Details
| Commodity | 300 Series 316 Stainless Steel Plate |
| Grade | 301,302,304,304L,316,316L,310S,309S,321,301,310 |
| Brand | TISCO ,BAOSTEEL,POSCO,JISCO,LISCO |
| Certification | SGS,BV,IQI,TUV,ISO,etc |
| Thickness | 0.3mm-3.0mm |
| Width | 1000,1219,1250,1500mm, or as your requirements |
| Length | 2000,2438,2500,3000,6000mm, or as your requirements |
| Surface | No.1, 2B, BA, 8K Mirror, Hairline,satin, Embossed,brush,No.4,HL,matt,pvc film,laser film. |
| Standard | ASTM,AISI,SUS,JIS,EN,DIN,GB, ASME,etc |
| Delivery | 5-7 days after confirming the order |
| MOQ | 1 Ton |
| C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 316 (S31600) |
0.08 max |
2.0 max |
0.75 max |
0.045 max |
0.03 max |
min: 16.0 max: 18.0 |
min: 2.0 max: 3.0 |
min: 10.0 max: 14.0 |
0.10 max |
| 316L (S31603) |
0.03 max |
2.0 max |
0.75 max |
0.045 max |
0.03 max |
min: 16.0 max: 18.0 |
min: 2.0 max: 3.0 |
min: 10.0 max: 14.0 |
0.10 max |
| Grade | Tensile Strength ksi (min) |
Yield Strength 0.2% ksi (min) |
Elongation % | Hardness (Brinell) MAX | Hardness (Rockwell B) MAX |
| 316 (S31600) |
75 | 30 | 40 | 217 | 95 |
| 316L (S31603) |
70 | 25 | 40 | 217 | 95 |
And compared to traditional oxygen acetylene, such as plasma cutting technology, laser cutting speed, narrow kerf width, small heat affected zone, vertical degree good, trimming smooth kerf edge, at the same time can be variety of laser cutting materials, including carbon steel, stainless steel, alloy steel, wood, plastic, rubber, cloth, quartz, ceramic, glass, composite materials, etc.With the rapid development of market economy and the progress of science and technology, laser cutting technology has been widely used in automobile, machinery, electricity, hardware and electrical appliances and other fields.
