Place of Origin: | Shanghai ,Shanxi |
---|---|
Brand Name: | BAOSTEEL , TISCO ,HONGWANG ,LISCO |
Certification: | ISO ,SGS,BV |
Model Number: | 300 Series 316l |
Minimum Order Quantity: | 1 ton according to products |
Price: | Negotiation |
Packaging Details: | Export Package |
Delivery Time: | 5-10 working days |
Payment Terms: | L/C, T/T, D/P, Western Union |
Supply Ability: | 2000 ton/Month |
Thickness: | 0.3-25mm | Finish: | 2B ,Hairilne,BA,NO6,N0 8 |
---|---|---|---|
Width: | 1000mm,1219mm,1250mm,1500mm | Color: | Natural Surface Or As Customized |
Market: | USA ,the Middle East,South Africa | Length: | 2500mm.6000mm |
Highlight: | 316 stainless steel plate,316l stainless steel plate |
Customized 316L 316 Stainless Steel Sheet AISI, ASTM, GB Mirror BA Finish
WUXI AOXIANG METAL inventory includes 316/316L (UNS S31600 / S31603), in sheet, sheet coil, plate, plate coil, bar, structural and tubular products. Generally, this grade is dual-certified to meet both 316 and 316L. Alloy 316/316L is ideally suited for applications requiring corrosion resistance superior to Type 304 and has good elevated temperature strength.
Features
316L: A low carbon version of 316 ,excellent to resistance to inter-granular corrosion in more corrosive environment.
316Ti: 316 grade with addition of Ti, excellent formabihty, good impact property of weld bead at extremely low temperature environment.
Products Details
1. Commodity: 300 Series 316l Stainless Steel Plate
2. Grade: 301,302,304,304L,316,316L,310S,309S,321,301,310
3. Brand: TISCO ,BAOSTEEL,POSCO,JISCO,LISCO
4. Certifacate: SGS,BV,IQI,TUV,ISO,etc
5. Thickness: 0.3mm-25mm
6. Width: 1000,1219,1250,1500mm, or as your requirements
7. Standard: ASTM,AISI,SUS,JIS,EN,DIN,GB, ASME,etc
Chemical Composition and Properties
Chemical Composition
Specification | Grade | Chemical Composition(wt%) | ||||||
C | Mn | Ni | Cr | Mo | Ti | |||
ASTMJIS | 316L/022Cr17Ni12Mo2 | ≤0.03 | ≤2.0 | 10.0-14.0 | 16.0-18.0 | 2.0-3.0 | - | |
JIS | SUS316L | ≤0.03 | ≤2.0 | 12.0-15.0 | 16.0-18.0 | 2.0-3.0 | - | |
ASTMJIS | 316Ti/SUS 316Ti | ≤0.08 | ≤2.0 | 10.0-14.0 | 16.0-18.0 | 2.0-3.0 | 5*(C+N)-0.7 |
Properties
Spec | Grade | Mechanical Property | Physical Property | ||||
Y.S (N/MM2) |
T.S (N/MM2) |
EL (%) |
HRB |
Specific Heat (J/g℃) |
Modulus of Elasticity (KN/mm2) | ||
ASTM/GB | 316L/022Cr17Ni12Mo2 | ≥170 | ≥485 | ≥40 | ≤95 | 0.5 | 193 |
JIS | SUS316L | ≥175 | ≥480 | ≥40 | ≤90 | 193 | |
ASTM | 316Ti | ≥205 | ≥515 | ≥40 | ≤95 | 0.5 | 200 |
316L: Widely used in corrosion-susceptible environment and some mechanical components those are difficult to make heat treatment after forming in more corrosive environment.
316Ti: Mainly used for industrial components.
Package
MOQ | 1 Ton |
Price Term | FOB CIF CNF |
Payment | L/C at sight or 30% TT as deposit |
Delivery Time | 5-10 days after receiving deposit by T/T or L/C. |
Sample | Samples free and express charges bear by you |
Standard export package with Kraft paper with wooded trays or as required,containers sizes as follows
20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high) about 24-26CBM, 23MTS
40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high) about 54CBM, 27MTS
40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high) about 68CBM, 27MTS
