Welded PN16 / 10 Flange Stainless Steel Pipe Fittings ASTM A182 WN / SO / BL / SW

Place of Origin Zhejiang, China
Brand Name XINFUTIAN
Certification BV,TUV,DNV,SGS,CE,LR.
Model Number 201, 304, 316L, 2205, 2207
Minimum Order Quantity 1PC
Price Negotiation
Packaging Details Wooden Cartons and Plastic Bag of each good.
Delivery Time 5 - 15 working days
Payment Terms T/T, L/C, Western Union
Supply Ability 1000 Ton / Month
Product Details
Technics Forged Type Flange
Model Number SUS201, SUS304, SUS316, F304,F316 ,SS321 Connection Welding
Flange Type RF WN Surface Pickling And Polishing
Quality Prime Pressure Class150 / 300 / 600 / 900 /1500 / 2500
High Light

flange stainless steel pipe fittings

,

stainless steel elbow fitting

Leave a Message
Product Description

ASTM A182 WN / SO / BL / SW Welded PN16 / 10 Stainless Steel Pipe Fittings Flange





Product Details


Product Name


ASTM A182 WN / SO / BL / SW Welded PN16 / 10 Stainless Steel Pipe Fittings Flange


Size


OD:1/8"-100"(6-2500mm)
WT:SCH5S-SCHXXS(1-150mm)


Standard


ASTM A182 WN / SO / BL / SW, DIN2605,DIN2615,DIN2616,DIN2633


Material


304, 316L, 321, 310S, 1.4301, 1.4307, 1.4404, S31803, S32750, 904L, Monel 400, Inconel 800


Surface


Pickling and bright


Certificate


ISO9001, CE, SGS, TUV, DNV, BV, LR, GL, NK, RMRS
Packing:              In wooden cases

Shipment


By sea, by air, by express




Chemical Composition(%)

Grade C Si Mn P S Cr Ni Mo

Cu


201 ≤0.15 ≤0.75 5.5~7.5 ≤0.060 ≤0.03 16.00~18.00 3.5~5.5 - 0.08

1.5


202 ≤0.15 ≤1.00 7.5~10.00 ≤0.060 ≤0.03 17.00~19.00 4.0~6.0 -




301 ≤0.15 ≤1.00 ≤2.00 ≤0.045 ≤0.03 16.00~18.00 6.00~8.00 -




302 ≤0.15 ≤1.00 ≤2.00 ≤0.035 ≤0.03 17.00~19.00 8.00~10.00 -




304 ≤0.07 ≤1.00 ≤2.00 ≤0.045 ≤0.03 18.00~20.00 8.00~10.50 -




304L ≤0.030 ≤1.00 ≤2.00 ≤0.045 ≤0.03 18.00~20.00 9.00~13.00 -




310S ≤0.08 ≤1.00 ≤2.00 ≤0.045 ≤0.03 24.00~26.00 19.00~22.00 -




316 ≤0.08 ≤1.00 ≤2.00 ≤0.045 ≤0.03 16.00~18.00 10.00~14.00 2.00~3.00




316L ≤0.03 ≤1.00 ≤2.00 ≤0.045 ≤0.03 16.00~18.00 12.00~15.00 2.00~3.00




321 ≤0.08 ≤1.00 ≤2.00 ≤0.045 ≤0.03 17.00~19.00 9.00~13.00 -




430 ≤0.12 ≤0.75 ≤1.00 ≤0.040 ≤0.03 16.00~18.00




-
2205 ≤0.03 ≤1.00 ≤2.00 ≤0.030 ≤0.015 22.00~23.00 4.5~6.5 2.5~3.5




2507 ≤0.03 ≤0.08 ≤1.20 ≤0.035 ≤0.015 24.00~26.00 6.00~8.00 3.0~5.0




904L ≤0.02 ≤1.00 ≤2.00 ≤0.045 ≤0.035 19.00~23.00 23.00~28.00 4.0~5.0 1.0~2.0




INCONEL
028

≤0.03 ≤1.00 ≤2.50 ≤0.030 ≤0.030 ≤28.0 ≤34.0 ≤4.0 ≤1.4




MONEL
400

≤0.30 ≤0.5 ≤2.00 - ≤0.024 - ≥63.0 - ≤34.0

INCONEL
800

≤0.10 ≤1.00 ≤1.50 - ≤0.015 ≤23.0 ≤35 4.0~5.0 ≤0.75

Ti≤0.6
Al≤0.6



1. HS CODE: 7307230000,7307210000

2. Trade term: FOB,CNF,CIF

3. Payment term: 30% by T/T as down payment balance against B/L copy or 100% LC at sight.

4. Delivery time: Within 3-15 working days after received deposit or LC draft.

5. A copy of mill test certificate will be provided with shipment.

Welded PN16 / 10 Flange Stainless Steel Pipe Fittings ASTM A182 WN / SO / BL / SW 0



FAQ

1. CAN I GET SOME SAMPLES?Yes. We can provide samples, you need to pay the sample fee and shipping cost in advance. We will refund the sample fee after you place your order. Please let us know your courier account or send us your fees and we will arrange to send you a sample.
2. CAN YOU PRODUCE ACCORDING TO THE SAMPLES?
Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
3. WHAT IS YOUR TERMS OF PAYMENT?
Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance, balance before shippment. If you have another question,pls feel free to contact us ASAP.
4. WHAT IS YOUR TERMS OF DELIVERY?
EXW, FOB, CFR, CIF, DDU.
5. CAN WE VISIT YOUR FACTORY?
Warmly welcome. Once we have your schedule, we will arrange the professional sales team to follow up your case.
6. HOW ABOUT YOUR DELIVERY TIME?
Generally speaking, 10 to 25 days after receiving your advance payment. The exact delivery time depends on the goods and quantity you ordered.
7. AFTER-SALE ADVANTAGES.
Year warranty for products; If you find any defective parts for the first time, we will provide you with new parts for free in the next order. As an experienced manufacturer, you can be assured of quality and after-sales service.
