Ferrite 430 Stainless Steel Strip Coil Cold Rolling BA 2B Finish Good Formability

Brand Name:	BAOSTEEL , TISCO ,HONGWANG ,LISCO，
Model Number:	400 Series 430
MOQ:	1 ton according to products
Price:	Negotiation
Payment Terms:	L/C, T/T, D/P, Western Union
Supply Ability:	2000 T/Month

Detail Information

Product Description

Detail Information

Place of Origin:

Shanghai ,Shanxi

Certification:

ISO ,SGS,BV

Thickness:

0.3-6mm

Finish:

NO 1,2B ,BA

Width:

6-600mm

Color:

Natural Surface Or As Customized

Standard:

JIS/ASTM/BN

Shape:

Plate

Packaging Details:

Export Package

Supply Ability:

2000 T/Month

Highlight:

316 stainless steel strip

polished stainless steel strips

Product Description

Ferrite 430 BA 2B Cold Rolling Stainless Steel Strip Coil Width 5 - 500mm Customized

Grade 430 is a ferritic, straight chromium, non-hardenable grade, combining good corrosion resistance and formability characteristics with useful mechanical properties. Its ability to resist nitric acid attack permits its use in specific chemical applications but automotive trim and appliance components represents its largest fields of application.

1. Products Details

UNS: ASTM/ASTE S43000
DIN: 1.4016

Grade	Ferrite 430 stainless steel strip
Thinckness	0.3-6.0mm
Tolerance	+/-0.02mm
Widthness	6mm-600mm
Length	as coils
Brand name	TISCO,L;ISCO,BAOSTEEL
Standard	JIS, AISI, ASTM, GB, DIN, EN ,etc.
Finish	2B, NO1,Hairline, No.4, BA, 8K mirror, etc.
Certification	SGS
Packaging	Standard exporting packing; seaworthy package.
MOQ	1 Tons
Price time	FOB, CFR, CIF, CNF
Delivery time	Within 15-20 working days after receiving your deposit
Payment	30% T/T in advanced+70% balanced; irrevocable L/C at sight
Remarks	Insurance is all risks and accept the third party test

2. Chemical Properties: 430 430F

Grade

430

min.

max.

0.12

1.00

0.040

0.030

16.0

18.0

0.75

430F

min.

max.

0.12

1.25

1.00

0.06

0.15

16.0

18.0

Mechanical Properties:

Grade	Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Hardness
Grade	Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Rockwell B (HR B) max	Brinell (HB) max
430	450	205	22	89	183
430F	552 typical	379 typical	25 typical	-	262

Physical Properties:

Grade	Density (kg/m³)	Elastic Modulus (GPa)	Mean Coefficient of Thermal Expansion (mm/m/°C)			Thermal Conductivity (W/m.K)		Specific Heat 0-100^°C (J/kg.K)	Electrical Resistivity (nW.m)
Grade	Density (kg/m³)	Elastic Modulus (GPa)	0-100°C	0-315°C	0-538°C	at 100°C	at 500°C	Specific Heat 0-100^°C (J/kg.K)	Electrical Resistivity (nW.m)
430	7750	200	10.4	11.0	11.4	23.9	26.0	460	600
430F	7750	200	10.4	11.0	11.4	26.1	26.3	460	600

3. Applications

The higher alloyed stainless steels generally have excellent strength at elevated temperatures along with outstanding resistance to creep deformation and environmental attack.

Furnace Parts
Oil Burner Parts
Heat Exchangers
Welding Filler Wire and Electrodes
Annealing Covers
Combustion Tubes
Fire Box Sheets
