| Place of Origin: | Shanghai ,Shanxi |
|---|---|
| Brand Name: | BAOSTEEL , TISCO ,HONGWANG ,LISCO， |
| Certification: | ISO ,SGS,BV |
| Model Number: | 300 Series 304 |
| Minimum Order Quantity: | 1 ton according to products |
| Price: | Negotiation |
| Packaging Details: | Export Package |
| Delivery Time: | 5-10 working days |
| Payment Terms: | L/C, T/T, D/P, Western Union |
| Supply Ability: | 2000 T/Month |
| Thickness: | 3-120mm | Finish: | NO 1 |
|---|---|---|---|
| Width: | 1000mm,1219mm,1250mm,1500mm | Color: | Natural Surface Or As Customized |
| Application: | Industry,Agriculture | Length: | As Customized |
| High Light: | stainless steel sheet 2b finish,hairline finish stainless steel sheet |
||
Astm A240 304 NO1 1500*6000 Ex-Stock 8mm 10mm For Construction
300 Series Stainless steel alloys resist corrosion, maintain their strength at high temperatures and are easy to maintain.
304 standards CHINA:06Cr19Ni10 ASTM/ASME: S30400 DIN: 1.4301
1. Products Details
| Commodity | 300 Series 316 Stainless Steel Plate |
| Grade | 301,302,304,304L,316,316L,310S,309S,321,301,310 |
| Brand | TISCO ,BAOSTEEL,POSCO,JISCO,LISCO |
| Certification | SGS,BV,IQI,TUV,ISO,etc |
| Thickness | 3mm-120mm |
| Width | 1000,1219,1250,1500mm, or as your requirements |
| Length | 2000,2438,2500,3000,6000mm, or as your requirements |
| Surface | No.1 |
| Standard | ASTM,AISI,SUS,JIS,EN,DIN,GB, ASME,etc |
| Delivery | 5-7 days after confirming the order |
| MOQ | 1 Ton according to products |
C:≤0.08 ,Si :≤1.0 ,Mn :≤2.0 ,Cr :18.0～20.0 ,Ni :8.0～10.0,S :≤0.03 ,P :≤0.045
3. Applications:
Food preparation equipment, especially in chloride environments
Chemical processing, equipment
Laboratory benches and equipment
Rubber, plastics, pulp & paper machinery
Pollution control equipment
Boat fittings, value and pump trim
Heat exchangers
Pharmaceutical and textile industries
Condensers, evaporators and tanks
4. Processing
Mostly Stainless steel sheet cut from stainless steel coil ,but according to the thickness.If thickness is very thick ,it will be sheets directly.Below are some steps of sheets process.
1. GRINDING
Grinding finish, also called brushed, directional or satin finish. coil or sheet...
2. POLISHING
polished stainless steel sheet uses grinding fluid to polish by polishing equipment on stainless steel ..
3. PVD COLOR COATING
PVD means Physical Vapor Deposition,working in vacuum condiction.....
4. ETCHING
Etching is corrode different kinds of patterns on stainless steel surfaces by chemical methods.
5. EMBOSSING
It is physical rolling on the stainless steel surface, pattern comes from metal roller....
5. Package
Standard export package with Kraft paper with wooded trays or as required,containers sizes as follows
20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high) about 24-26CBM, 23MTS
40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high) about 54CBM, 27MTS
40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high) about 68CBM, 27MTS
Q: What's your main Products?
A:We provide stainless steel coil, sheet and strips in 200/300/400 series.
Q: What's the minimum quantity?
A: It is 500kg.
Q: What is your delivery time?
A:We have monthly stock material of 5700 tons, making sure our delivery time of 7-10 days.
Q: Which payment term will you accept?
A: Payment term is T/T, L/C,Kunlun bank, O/A, Paypal,Western Union and so on.
And we could acceptable 100%L/C or O/A for payment.
Water Jet Machining Center
The process parameters: processing range: 2-200mm
Widthest: 10m
Surface: smooth
Precision: ±0.1mm
