Silver Cold Rolled Steel Plate Thickness 18 20 24 Gague Stainless Steel Sheets 4x8 2B Finish
Place of Origin | Shanghai |
---|---|
Brand Name | TISCO, BAOSTEEL, ZPSS, LISCO, ect |
Certification | ISO, SG, MTC |
Model Number | 904L |
Minimum Order Quantity | 1 ton |
Price | Negotiation |
Packaging Details | Interlayer paper kraft paper Wooden pallet or according to customer's request. |
Delivery Time | 7-15 working days |
Payment Terms | L/C, T/T |
Supply Ability | 1000TON Per month |
Edge | Slit Edge | Material | Cold Rolled Stainless Steel Sheet 904L |
---|---|---|---|
Thickness | 0.3-3mm | Size | 1000mm*2000mm, 1219mm*2438mm, 1219mm*3048mm, |
Sample | Free Sample | Color | Bright |
High Light | cold rolled steel plate,cold rolled stainless steel |
Silver Cold Rolled Steel Plate Thickness 18 20 24 Gague Stainless Steel Sheets 4x8 2B Finish
1. Chemical Composition
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Cu | |
904L |
min. max. |
- 0.02 |
- 2 |
- 1 |
- 0.045 |
- 0.035 |
19 23 |
4 5 |
23 28 |
1 2 |
Proprerties
Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
Rockwell B (HR B) | Brinell (HB) | ||||
904L | 490 | 220 | 36 | 70-90 typical | 150 |
2. Corrosion Resistance
Grade 904L stainless steels have excellent resistance to warm seawater and chloride attack. The high resistance of grade 904L against stress corrosion cracking is due to the presence of high amounts of nickel in its composition. Moreover, the addition of copper to these grades develops resistance to sulphuric acid and other reducing agents in both aggressive and mild conditions
The corrosion resistance of grade 904L is intermediate between super austenitic grades, with 6% molybdenum content, and standard 316L austenitic grades. Grade 904L is less resistant to nitric acid than grades 304L and 310L, which are free of molybdenum.
3. Application
Some of the major applications of grade 904L stainless steels include:
Wiring in electrostatic precipitators,Oil refinery components
Seawater cooling devices,Gas scrubbing plants
Pulp and paper processing industries
Acetic, phosphoric and sulphuric acid processing plants
