| Place of Origin: | Shanghai |
|---|---|
| Brand Name: | TISCO, BAOSTEEL, ZPSS, LISCO, ect |
| Certification: | ISO, SG, MTC |
| Model Number: | 400 Series 430 |
| Minimum Order Quantity: | 1 ton |
| Price: | Negotiation |
| Packaging Details: | Interlayer paper kraft paper Wooden pallet or according to customer's request. |
| Delivery Time: | 7-15 working days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 1000TON Per month |
| Finish: | Mill Finish | Material: | Cold Rolled Stainless Steel Sheet 430 |
|---|---|---|---|
| Thickness: | 0.3-3.0mm | Size: | 1000mm*2000mm, 1219mm*2438mm, 1219mm*3048mm, |
| Sample: | Free Sample | Color: | Bright |
| High Light: | cold rolled stainless steel,stainless steel cold rolled sheet |
||
BA Finished Inox 430 Stainless Steel Sheet Metal DIN1.4016 1219 X 2438MM
Quick Detail
430 stainless steel sheet
size: 1000x2000mm 1219x2438mm 1500x3000mm
thickness: 0.3-3.0mm cold rolled
3.0-120mm hot rolled
we have 430 stainless steel coils in stock, we can cut the coil for any length as customer required.
the size of our coil
slit coil: 1000mm 1219mm 1500mm
mile coil: 1020-1060mm 1220-1265mm 1520-1270mm
430 stainless steel sheet
| PRODUCTS | 430 stainless steel sheet | Brand | TISCO BAOSTEEL JISCO |
size |
1219x2438mm 1000x2000mm Or as required |
surface |
2B other surface is available |
| thickness | 0.3-3.0mm | Certificate | SGS, BV |
Chemical Composition for stainless steel sheet
| Specification | Grade | Chemical Composition(Wt%) | ||||
| C | Mn | P | S | Cr | ||
| ASTM | 430 | ≤0.12 | ≤1.00 | ≤0.040 | ≤0.030 | 16.0-18.0 |
| JIS | SUS430 | ≤0.12 | ≤1.00 | ≤0.040 | ≤0.030 | 16.0-18.0 |
| GB | 10Cr17 | ≤0.12 | ≤1.00 | ≤0.040 | ≤0.030 | 16.0-18.0 |
| Specification | Grade | Mechanical Property | Physical Property | ||||
|
Y.S (N/mm2) |
T.S (N/mm2) |
EL (%) |
HRB |
Specific Heat (J/g℃) |
Modulus of Elasticity (KN/mm2) |
||
| JIS | SUS430 | ≥205 | ≥420 | ≥22 | ≤88 | ||
Feather and Applications
430 stainless steel board has all the characteristics of the 430 stainless steel, is with good corrosion resistance and general steel grade, heat conduction performance is better than austenitic, thermal expansion coefficient is smaller than austenitic, thermal fatigue, add a stabilizing element titanium, weld parts mechanical performance is good, it is mainly used for building decoration, fuel burner components, home appliances, home appliance parts.
