16 / 24 / 30 Gauge Cold Rolled Stainless Steel Sheet Coil Ferrite 439 / 1.4509

  • 16 / 24 / 30 Gauge Cold Rolled Stainless Steel Sheet Coil Ferrite 439 / 1.4509
  • 16 / 24 / 30 Gauge Cold Rolled Stainless Steel Sheet Coil Ferrite 439 / 1.4509
  • 16 / 24 / 30 Gauge Cold Rolled Stainless Steel Sheet Coil Ferrite 439 / 1.4509
Place of Origin Shanghai
Brand Name TISCO ,BAOSTEEL,BAOXIN
Certification ISO,BV,ISO,SGS
Model Number 439 1.4509
Minimum Order Quantity 2 ton
Price Negotiation
Packaging Details Standard Seaworthy package or as the customer's requirement.
Delivery Time 5-10 working days
Payment Terms L/C, T/T, Western Union, D/A
Supply Ability 2000 Ton/Month
Product Details
Technology Cold Rolled Type Sheet,Rod,Pipe,Coil
Item Stainless Steel Coil Sheet Shipping Air,Sea
Thickness 0.3-3.0mm Surface Treatment BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D, HL, 8K, 2B, BA
High Light

cold rolled steel plate

,

cold rolled stainless steel
Leave a Message
Product Description



16 / 24 / 30 Gauge Cold Rolled Steel Sheet Coil Ferrite 439 / 1.4509



1.439 stainless steel



Type 439 Stainless Steel is a ferritic stainless steel designed to resist corrosion in a variety of oxidizing environments from fresh water to boiling acids. It may be used in either the annealed, cold formed or as-welded condition in many applications where other stainless steel alloys such as Type 304, Type 410, Type 409 and Type 430are used.



The 439 steel grade is based on the ordinary ferrite material (430) to reduce the content of C, and the addition of stabilizing elements such as Ti, so that the steel species have improved intergranular corrosion resistance, formability and weldability. Compared with the 304 steel grade, the elongation is low (about 30%), but the strength and corrosion resistance are equivalent, and the corrosion resistance is better than the 200 series materials.



chemical composition



Carbon 0.030 max.     Manganese 1.00 max.    Sulfur 0.030 max.
Phosphorus 0.040 max.       Silicon 1.00 max.     Chromium 17.0 – 19.0
Nickel 0.50 max.        Nitrogen 0.030 max.       Aluminum 0.15 max.
Titanium [0.20+4x(C+N)] min. – 0.75 max.



MECHANICAL PROPERTIES



Type Yield Strength 0.2% offset (KSI)

Tensile Strength (KSI) %

Elongation (2″ Gauge length)
439 Ann 30 min. 60 min. 22 min.



Country Standard Grade (%)Chemical Composition
　　
　　
　　
　　
　　
　　
　　
　≤　

　　
　　
　　		 C Si Mn P S Cr Ni 　N　 Ti
USA ASTM 439 0.03 1.00 1.00 0.04 0.03

17.0-

19.0

≤

0.5

≤

0.04

 0.2+4(C+N)－1.10
Ger DIN 1.4510 0.05 1.00 0.00 0.04 0.015 16.0-18.0 - - 4(C+N)－0.80



 Main purpose



Decoration board for elevator and escalator

Building decoration board, such as decorative structural parts, structural pipe

Automobile exhaust system components

Washing machine inner drum

16 / 24 / 30 Gauge Cold Rolled Stainless Steel Sheet Coil Ferrite 439 / 1.4509 0



Progress of  Coil  Cutting line

16 / 24 / 30 Gauge Cold Rolled Stainless Steel Sheet Coil Ferrite 439 / 1.4509 1



What other products you need  ?  Contact us

16 / 24 / 30 Gauge Cold Rolled Stainless Steel Sheet Coil Ferrite 439 / 1.4509 2
