Prime Hot Rolled Steel Plates / Panels Roll 347H TISCO Brand Thin Thickness

Place of Origin Shanxi
Brand Name TISCO
Certification ISO ,SGS,BV
Model Number 347H
Minimum Order Quantity 1 ton according to products
Price Negotiation
Packaging Details Export Package
Delivery Time 5-10 working days
Payment Terms L/C, T/T, D/P, Western Union
Supply Ability 1000 T/Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Steel Grade 300 Series 347H Application Decoration,Construction,boiler,oil And Gas,electric
Standard AISI,GB,DIN,JIS Length 3000mm~6000mm,6 Meters Or Customized
Thickness 3mm-20mm Width 1000-2000mm, Or As Required, 1000/1219/1500/1524/1800/2000, 1000/1200/1219/1220/1250/1500/1800mm, 150mm-2500mm
High Light

mirror finish stainless steel sheet

,

hairline finish stainless steel sheet

Leave a Message
Product Description



Prime Hot Rolled Steel Plates / Panels Roll 347H TISCO Brand Thin Thickness



Grade: 347H

Thickness: 6-20mm

Length: 6000mm or as customzied

Brand : BAOSTEEL,TISCO

Standard: ISO,ASTM,SUS,GB

Surface: NO1

Place of origin: China (mainland)

Payment terms : 30% TT as deposit or L/C at sight



Chemical Composition



  SS 347H
Ni 9 – 13
Cr 17 – 19
C 0.04 – 0.10
Mo 3 – 4
Fe Balance
Mn 2 max
Si 0.75 max
S 0.03 max
P 0.045 max
Co + Ta 8xC min
1.00 max




Mechanical & Physical Properties



Density 8.0 g/cm3
Melting Point 1454 °C (2650 °F)
Tensile Strength Psi – 75000 , MPa – 515
Yield Strength (0.2%Offset) Psi – 30000 , MPa – 205
Elongation 35 %



Applications

  • Aerospace – piston engine manifolds
  • Chemical Processing
  • Expansion Joints
  • Food Processing – equipment and storage
  • Petroleum Refining – polythionic acid service
  • Waste Treatment – thermal oxidizers

Benefits

  • Higher creep stress and rupture properties when compared with 304
  • Ideal for high temperature service
  • Overcomes sensitization and intergranular corrosion concerns
  • Can be used in elevated temperature applications for ASME Boiler and Pressure Vessel Code applications
  • Due to stabilisation the material offers better overall corrosion resistance when compared to 304/304L
  • Excellent mechanical properties
  • A high carbon version (347H) is also available
