| Place of Origin: | Shanghai ,Shanxi |
|---|---|
| Brand Name: | BAOSTEEL , TISCO ,HONGWANG ,LISCO， |
| Certification: | ISO ,SGS,BV |
| Model Number: | 300 Series 317L |
| Minimum Order Quantity: | 1 ton according to products |
| Price: | Negotiation |
| Packaging Details: | Export Package |
| Delivery Time: | 5-10 working days |
| Payment Terms: | L/C, T/T, D/P, Western Union |
| Supply Ability: | 2000 T/Month |
| Thickness: | 3-120mm | Finish: | NO 1 |
|---|---|---|---|
| Width: | 1000mm,1219mm,1250mm,1500mm | Color: | Natural Surface Or As Customized |
| Standard: | JIS/ASTM/BN | Shape: | Plate |
| High Light: | stainless steel sheet 2b finish,hairline finish stainless steel sheet |
||
Customized Hot Rolled Stainless Steel Plate 300 Series 317L NO1 Finish
1. Products Details
317L (00Cr19Ni13Mo3, UNS S31726) alloy is based on molybdenum-based austenitic stainless steel. It has a stronger resistance to chemical corrosion than conventional chromium-nickel austenitic stainless steels such as 304 alloys. In addition, compared with conventional stainless steel, 317L alloy has a higher ductility, stress corrosion resistance, compressive strength and high temperature performance. It is a low carbon grade or L grade, which has an anti-sensitization performance during and during heat treatment.
| Grade | 317L stainless steel sheet |
| Thinckness | 3-120mm |
| Tolerance | +/-0.02mm |
| Widthness | 1500mm,1800mm,2000mm or as customized |
| Length | 6000mm or as customized |
| Brand name | TISCO,L;ISCO,BAOSTEEL |
| Standard | JIS, AISI, ASTM, GB, DIN, EN ,etc. |
| Finish | 2B, NO1,Hairline, No.4, BA, 8K mirror, etc. |
| Certification | SGS |
| Packaging | Standard exporting packing; seaworthy package. |
| MOQ | 1 Tons |
| Price time | FOB, CFR, CIF, CNF |
| Delivery time | Within 15-20 working days after receiving your deposit |
| Payment | 30% T/T in advanced+70% balanced; irrevocable L/C at sight |
| Remarks | Insurance is all risks and accept the third party test |
| 317L | C | Si | Mn | P | S | Ni | Cr |
| ≤0.03 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 11.0-15.0 | 18.00~20.00 |
SUS317 L Mechanical properties
YS(Mpa)≥176,TS(Mpa)≥480,EL(%)≥40,Hv≤200
2. APPLICATIONS
Relative 316 l, 317 l steel has excellent water resistance and resistance to SCC, used for Chemical ships, Chemical products, such as Reactor should be high corrosion-resistant Chemical equipment
3. Hot Rolling Production Line For 317L SHEET
|
Thickness |
Witth |
Length |
Precision |
Straightness |
Length Error |
Trimedge Thickness |
| 3.0-8.0 | 800-1600 | 1000-150000 | ≤±1.5 | ≤±1.0 | ≤±1.5 | ≤8.0 |
| 6.0-14.0 | 1000-2000 | ≤14.0 | ||||
| 8.0-18.0 | 1250-2000 | ≤16.0 |
317L SS Sheet In Stock
| NO.1 Finish | T*W*L | W*L | W*L |
| NO.1 Finish | 3.0*1500*6000 | 1800*6000 | 2000*6000 |
| NO.1 Finish | 4.0*1500*6000 | 1800*6000 | 2000*6000 |
| NO.1 Finish | 5.0*1500*6000 | 1800*6000 | 2000*6000 |
| NO.1 Finish | 6.0*1500*6000 | 1800*6000 | 2000*6000 |
| NO.1 Finish | 8.0*1500*6000 | 1800*6000 | 2000*6000 |
| NO.1 Finish | 10*1500*6000 | 1800*6000 | 2000*6000 |
| NO.1 Finish | 12*1500*6000 | 1800*6000 | 2000*6000 |
| NO.1 Finish | 14*1500*6000 | 1800*6000 | 2000*6000 |
