AISI 430 Hot Rolled Stainless Steel Sheet Mirror Finishing High Thermal

Place of Origin Shangxi
Brand Name BAOSTEEL,TISCO,JISCO ,LZ
Certification BV,SGS,ISO
Model Number 400 Series 430
Minimum Order Quantity Negotiation
Price Negotiation
Packaging Details Standard export seaworthy package or as customer required
Delivery Time 5-8 working days
Supply Ability 2000 ton/Month
Product Details
Name Hot Rolled Stainless Steel Sheet Standard AISI 430
Width 1500,1800,2000mm Length 6000mm
Type Plate Surface Mirror Finishing
High Light

stainless steel sheet 2b finish

,

mirror finish stainless steel sheet

Leave a Message
Product Description

AISI 430 Hot Rolled Stainless Steel Sheet Mirror Finishing High Thermal



Hot Rolled Stainless Steel Sheet Application



High temperature components such as turbine blades, guide vanes, turbine disks, high pressure
compressor disks,machine manufacturing
and combustion chambers used in the manufacture of aviation, naval and industrial gas turbines



Hot Rolled Stainless Steel Sheet Features



1. A representative grade of ferritic stainless steel ,magnetic;

2. Low coeffcient of thermal expansion,high thermal;

3. Low cost without Ni and Mo contents;



Hot Rolled Stainless Steel Sheet Details



Grade 430 stainless steel sheet
Thinckness 3-120mm
Tolerance +/-0.02mm
Widthness 1500mm,1800mm,2000mm or as customized
Length 6000mm or as customized
Brand name TISCO,L;ISCO,BAOSTEEL
Standard JIS, AISI, ASTM, GB, DIN, EN ,etc.
Finish 2B, NO1,Hairline, No.4, BA, 8K mirror, etc.
Certification SGS
Packaging Standard exporting packing; seaworthy package.
MOQ 1 Tons
Price time FOB, CFR, CIF, CNF
Delivery time Within 15-20 working days after receiving your deposit
Payment 30% T/T in advanced+70% balanced; irrevocable L/C at sight
Remarks Insurance is all risks and accept the third party test



Specification Grade Chemical Composition(Wt%)
C Mn P S Cr
ASTM 430 ≤0.12 ≤1.00 ≤0.040 ≤0.030 16.0-18.0
JIS SUS430 ≤0.12 ≤1.00 ≤0.040 ≤0.030 16.0-18.0
GB 10Cr17 ≤0.12 ≤1.00 ≤0.040 ≤0.030 16.0-18.0



Specification Grade Mechanical Property Physical Property

Y.S

(N/mm2)

T.S

(N/mm2)

EL

(%)

HRB

Specific Heat

(J/g℃)

Modulus of Elasticity

(KN/mm2)

JIS SUS430 ≥205 ≥420 ≥22 ≤88
ASTM/GB 430 ≥205 ≥450 ≥22 ≤89 0.46 200



430 NO.I Satinless Steel Sheet In Stock



NO.1 Finish T*W*L W*L W*L
NO.1 Finish 3.0*1500*6000 1800*6000 2000*6000
NO.1 Finish 4.0*1500*6000 1800*6000 2000*6000
NO.1 Finish 5.0*1500*6000 1800*6000 2000*6000
NO.1 Finish 6.0*1500*6000 1800*6000 2000*6000
NO.1 Finish 8.0*1500*6000 1800*6000 2000*6000
NO.1 Finish 10*1500*6000 1800*6000 2000*6000
NO.1 Finish 12*1500*6000 1800*6000 2000*6000
NO.1 Finish 14*1500*6000 1800*6000 2000*6000



Equirements For NO1 Hot Rolling Production Line



Thickness

(mm)

Witth

(mm)

Length

(mm)

Precision

(mm)

Straightness

(mm)

Length Error

(mm)

Trimedge Thickness

(mm)

3.0-8.0 800-1600 1000-150000 ≤±1.5 ≤±1.0 ≤±1.5 ≤8.0
6.0-14.0 1000-2000         ≤14.0
8.0-18.0 1250-2000         ≤16.0
