Stainless Steel Sheet 316 , Food Grade Stainless Steel Plate As Custom Cut

Place of Origin NINGBO CHINA
Brand Name TISCO, BAOSTEEL, JISCO, ZPSS
Certification MTC BV SGS ISO
Model Number 316 316l Stainless Steel Sheet
Minimum Order Quantity 1 TON
Price Negotiation
Packaging Details Standard Seaworthy package or as the customer's requirement
Delivery Time 7-15 Working days
Payment Terms T/T L/C at sight
Supply Ability 1000Ton per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material 316 Stainless Steel Sheet Color Bright 2B Finshed
Surface 2B BA No.4 6k 8k Hairline Embossed Etched, Size 4(1219MM)X8 (2438MM) Or As Request
Type Sheet,plate Technology Clod Rolled
High Light

316 stainless steel plate

,

316 stainless steel sheet metal

Leave a Message
Product Description

Stainless Steel Sheet 316 , Food Grade Stainless Steel Plate As Custom Cut



1. Products Details



Stainless steel sheet / Stainless steel Plate

Material:201,304,316,316L,347,409,410,420,430,etc

Surface finish:mirror,polished,embossed,checkered,NO.1,NO.2D,NO.2B,BA,HL,NO.8,etc

Porduction Process:hot rolled,cold rolled

Property:corrosion resistance,high-temperature oxidation resistance,etc

Thickness:0.3~120mm

Width:600~2000mm

Length:1000~6000mm



Material

ASTM

201,202,301,304,304H,304L,304N,XM21,304LN,305,309S,309,310,310S,316,316Ti,

316L,316N,316LN,317,317L,321,321H,347,347H,329,405,409,430,434,444,403,410,

410S,420,440A,

TP201,TP202,TP304,TP304H,TP304L,TP305,TP309S,TP309H,TP310S,TP310H,

TP316,TP316H,TP316L,TP317,TP317L,TP321,TP321H,TP347,TP347H,etc

JIS

SUS201,SUS202,SUS301,SUS304,SUS304L,SUS304N1,SUS304N2,SUS304LN,

SUS305,SUS309S,SUS310S,SUS316,SUS316Ti,SUS316L,SUS316N,SUS316LN,

SUS316J1,SUS316JIL,SUS317,SUS317L,SUS321,SUS347,SUS329JI,SUS405,

SUH409,SUS410L,SUS409L,SUS410,SUS430,SUS434,SUS444,SUS403,SUS410,

SUS420J1,SUS420J2,SUS440A,etc

UNS

S20100,S20200,S30100,S30400,S30403,S30500,S30908,S31008,S31600,S31635,

S31603,S31700,S31703,S32100,S34700,S32900,S40500,S40900,S43000,S43400,

S44400,S40300,S41000,S42000,S44002,S30409,S30909,S31109,S31609,S32109,

S34709,S41008,etc

KS

STS201,STS202,STS301,STS304,STS304L,STS305,STS309S,STS310S,STS316,

STS316L,STS317,STS317L,STS321,STS347,STS329J1,STS405,STS409,STS410L,

STS430,STS434,STS403,STS410,STS420J1,STS440A,etc

EN

1.4372,1.4373,1.4319,1.4301,1.4306,1.4315,1.4303,1.4833,1.4845,1.4401,1.4571,

1.4404,1.4429,1.4438,1.4541,1.4550,1.4477,1.4462,1.4002,1.4512,1.4016,1.4113,

1.4509,1.4521,1.4006,1.4021,1.4028,etc





2. Chemical Properties:



  C Mn Si P S Cr Mo Ni N
316
(S31600)
0.08
max
2.0
max
0.75
max
0.045
max
0.03
max
min: 16.0
max: 18.0
min: 2.0
max: 3.0
min: 10.0
max: 14.0
0.10
max
316L
(S31603)
0.03
max
2.0
max
0.75
max
0.045
max
0.03
max
min: 16.0
max: 18.0
min: 2.0
max: 3.0
min: 10.0
max: 14.0
0.10
max

3. Mechanical Properties:

Grade Tensile Strength
ksi (min)
Yield Strength
0.2% ksi (min)
Elongation % Hardness (Brinell) MAX Hardness
(Rockwell B) MAX
316
(S31600)
75 30 40 217 95
316L
(S31603)
70 25 40 217 95




3.  Advantages:



Sample service

1: we can supply sample as your requirements, sample charge about USD10-50/pcs.

2: delivery time :after we receiving sample charge , we will send the sample to you within 3 days by

express (DHL,TNT).



Customized services

we can make other specification products according to your requirements.
