| Place of Origin: | NINGBO CHINA |
|---|---|
| Brand Name: | TISCO, BAOSTEEL, JISCO, ZPSS |
| Certification: | MTC BV SGS ISO |
| Model Number: | 304 Stainless Steel Sheet |
| Minimum Order Quantity: | Negotiable |
| Price: | Negotiation |
| Packaging Details: | Interlayer paper kraft paper Wooden pallet or according to customer's request. |
| Delivery Time: | 7-15 Working days |
| Payment Terms: | T/T L/C at sight |
| Supply Ability: | 1000 Ton per Month |
| Product Name: | 304 Stainless Steel Sheet | Surface: | No.4 6k 8k Hairline Embossed Etched, |
|---|---|---|---|
| Size: | Custom Made | Standard: | JIS, AISI, ASTM, GB, DIN, EN |
| Sample: | Can Be Available | Feature: | High Mechanical Properties |
| High Light: | 304 grade stainless steel sheet,embossed stainless steel sheets |
||
Custom Made 304 Stainless Steel Sheet High Mechanical Properties
304 Stainless Steel Sheet Introduction
Stainless steel has excellent corrosion resistance and high temperature resistance, and has good weldability and polishing performance.
It is widely used in high temperature applications, medical devices, building materials, chemistry, food industry, agriculture,ship components.
It also applies to food, beverage packaging, kitchen supplies, trains, aircraft, conveyor belts, vehicles, bolts,nuts, springs, and screen.
304 Stainless Steel Sheet Specifications
|
Grade
|
201.304,304L,316,316L,310S,309S,301,321,2205,2507 |
|
Brand
|
TISCO, LISCO, BAOSTEEL, BAOXIN, POSCO, JISCO, ZPSS |
|
Thickness
|
0.3-3.0mm |
|
Width |
1000,1219,1500 mm or as request |
|
Length
|
2438,3048or as request |
|
Size
|
1000mm*2000mm, 1219mm*2438mm, 1219mm*3048mm, or as required |
|
Color
|
Gold, black, sapphire blue, brown, bronze, purple, champagne gold, diamond, rose gold, rose red, etc |
|
Delivery Time
|
7~15 working days after the receipt of 30% deposit |
|
Packing
|
Interlayer paper kraft paper Wooden pallet or according to customer's request. |
304 Stainless Steel Sheet Chemical Composition
C:≤0.08 ,Si :≤1.0 ,Mn :≤2.0 ,Cr :18.0～20.0 ,Ni :8.0～10.0,S :≤0.03 ,P :≤0.045
304 Stainless Steel Sheet Pysical properties
|
Tensile strength σb (MPa |
≥ 520
|
Specific heat capacity(0 ~ 100 ℃, KJ kgK) |
0.50
|
|
Conditions yield strength |
σ0.2 (MPa) ≥ 205
|
Thermal conductivity (W m. K) |
(100 ℃), 16.3 21.5 (500 ℃)
|
|
Elongation δ5 (%) |
≥40
|
The linear expansion coefficient k. |
(0 ~ 100 ℃), 17.2 (0 ~ 500 ℃) of 18.4
|
|
Section shrinkage ψ (%) |
≥ 60
|
Resistivity (20 ℃, 10 Ω m.) |
0.73
|
|
Hardness |
≤ 187HB; ≤ 90HRB; ≤ 200HV
|
The longitudinal elastic modulus (20 ℃, KN/mm) |
193 |
|
Melting point (℃) |
1398 ~ 1454
|
Specific heat capacity |
0.50 |
3. Advantages of stainless steel
1. Mechanical properties: According to different types of stainless steel, different mechanical properties, martensitic stainless steel has high strength and high hardness, suitable for manufacturing parts that are both corrosion resistant and require high strength and high wear resistance, such as steam turbine shaft and stainless steel cutter. , stainless steel bearings, etc., austenitic stainless steel plasticity is very good, the strength is not high, but the best corrosion resistance is stainless steel, suitable for properties requiring high corrosion resistance and low mechanical properties, such as chemical plants, fertilizer plants, Sulfuric acid plant, equipment and equipment of hydrochloric acid plant, of course, can also be used in military industry such as submarine. Ferritic stainless steel has moderate mechanical properties and low strength, but it is resistant to oxidation and is suitable for various industrial furnace components.
2 .. Process performance: Austenitic stainless steel has the best process performance. Due to its good plasticity, it can be processed into various profiles such as plates and tubes. It is suitable for pressure treatment. Martensitic stainless steel has poor hardness due to its high hardness.
