430 No.1 Finish Cold Rolled Stainless Steel Sheet 0.3-3.0mm Thickness
| Place of Origin | Shanghai |
|---|---|
| Brand Name | TISCO, BAOSTEEL, ZPSS, LISCO, ect |
| Certification | ISO, SG, MTC |
| Model Number | 400 Series 430 |
| Minimum Order Quantity | 1 ton |
| Price | Negotiation |
| Packaging Details | Interlayer paper kraft paper Wooden pallet or according to customer's request. |
| Delivery Time | 7-15 working days |
| Payment Terms | L/C, T/T |
| Supply Ability | 1000TON Per month |
Product Details
| Name | Cold Rolled Stainless Steel Sheet | Material | 430 |
|---|---|---|---|
| Thickness | 0.3-3.0mm | Size | 1219mm*2438mm, 1219mm*3048mm, |
| Sample | Free Sample | Finish | No.1 Finish |
| High Light | cold rolled stainless steel,stainless steel cold rolled sheet |
||
Product Description
430 No.1 Finish Cold Rolled Stainless Steel Sheet 0.3-3.0mm Thickness
Cold Rolled Stainless Steel Sheet Quick Detail
Equal Grade From Different Standard Of 430
|
Standard |
ISO Name |
ASTM |
DIN / EN |
JIS |
GB |
|
430 |
X6Cr17 |
S43000 / 430 |
1.4016 |
SUS430 |
10Cr17 / 1Cr17 |
Chemical Component Of 430 Stainless Steel
|
430 |
C |
Si |
Mn |
P |
S |
Ni |
Cr |
Mo |
N |
|
ASTM |
0.12 |
1.00 |
1.00 |
0.04 |
0.030 |
0.75 |
16.0-18.0 |
- |
- |
|
DIN/EN |
0,08 |
1,00 |
1,00 |
0,04 |
0,015 |
- |
16,0-18,0 |
- |
- |
|
JIS |
0.12 |
0.75 |
1.00 |
0.04 |
0.030 |
- |
16.0-18.0 |
- |
- |
|
GB |
0.12 |
1.00 |
1.00 |
0.04 |
0.030 |
0.75 |
16.0-18.0 |
- |
- |
Mechanical property Of 430 Stainless Steel
|
430 |
Y.S./Mpa ≥ |
T.S./Mpa ≥ |
E.L./% ≥ |
HRB ≤ |
HBW ≤ |
|
HV ≤ |
|
ASTM |
205 |
450 |
22 |
- |
89 |
183 |
- |
|
JIS |
205 |
450 |
22 |
183 |
88 |
- |
200 |
|
GB |
205 |
450 |
22 |
- |
89 |
183 |
200 |
Cold Rolled Stainless Steel Sheet Feather and Applications
430 stainless steel board has all the characteristics of the 430 stainless steel, is with good corrosion resistance and general steel grade, heat conduction performance is better than austenitic, thermal expansion coefficient is smaller than austenitic, thermal fatigue, add a stabilizing element titanium, weld parts mechanical performance is good, it is mainly used for building decoration, fuel burner components, home appliances, home appliance parts.
