2D Finish 1.4509 / 439 Stainless Steel Strip Roll For Exhaust Pipe
| Place of Origin | Shanghai |
|---|---|
| Brand Name | TISCO ,BAOSTEEL |
| Certification | ISO,BV |
| Model Number | 439 1.4509 |
| Minimum Order Quantity | 2 ton |
| Price | Negotiation |
| Packaging Details | Standard Seaworthy package or as the customer's requirement. |
| Delivery Time | 5-10 working days |
| Payment Terms | L/C, T/T, Western Union, D/A |
| Supply Ability | 2000 Ton/Month |
Product Details
| Technology | Cold And Hot Rolled | Type | Sheet,Rod,Pipe,Coil |
|---|---|---|---|
| Item | Stainless Steel | Color | Natural |
| Shipping | Air,Sea | Thickness | 0.3-3.0mm |
| High Light | 439 Stainless Steel Strip Roll,1.4509 Stainless Steel Strip Roll,2D Stainless Steel Strip Roll |
||
Product Description
2D Finish 1.4509 / 439 Stainless Steel Strip Roll For Exhaust Pipe
chemical composition
| Country | Standard | Grade | (%)Chemical Composition | ≤ |
|||||||
| C | Si | Mn | P | S | Cr | Ni | N | Ti | |||
| USA | ASTM | 439 | 0.03 | 1.00 | 1.00 | 0.04 | 0.03 |
17.0- 19.0 |
≤ 0.5 |
≤ 0.04 |
0.2+4(C+N)－1.10 |
| Ger | DIN | 1.4510 | 0.05 | 1.00 | 0.00 | 0.04 | 0.015 | 16.0-18.0 | - | - | 4(C+N)－0.80 |
Mechanical Property
| Standard | Mechanical Property | |||
|
Tensile Strength |
Yield Strength | Elongation(%) | Hardness | |
| N/m㎡ | (≤)N/m㎡ | (≥)% | (≤)HV | |
| ASTM | ≥415 | 205 | 22 | 180 |
Main purpose
Decoration board for elevator and escalator
Building decoration board, such as decorative structural parts, structural pipe
Automobile exhaust system components
Washing machine inner drum
439 stainless steel
The 439 steel grade is based on the ordinary ferrite material (430) to reduce the content of C, and the addition of stabilizing elements such as Ti, so that the steel species have improved intergranular corrosion resistance, formability and weldability. Compared with the 304 steel grade, the elongation is low (about 30%), but the strength and corrosion resistance are equivalent, and the corrosion resistance is better than the 200 series materials.
