AISI 420HC EN 1.4034 Martensitic Grade Steel Plate 5mm Thickness

Place of Origin Shanghai ,Shanxi
Brand Name BAOSTEEL , TISCO ,HONGWANG ,LISCO
Certification ISO ,SGS,BV
Model Number 1.4034 Stainless Steel Sheets
Minimum Order Quantity Negotiable
Price Negotiation
Packaging Details Export Package
Delivery Time 5-10 working days
Payment Terms L/C, T/T, D/P, Western Union
Supply Ability 2000 T/Month
Product Details
Name 1.4034 Stainless Steel Sheets Type Sheet,plate
Thickness 3mm - 50mm Surface Finish 2B/BA/NO.1/NO.3/NO.4/HL
Size Support Custom-made Technique Hot Rolled
High Light

EN 1.4034 Martensitic Grade steel plate

,

AISI 420HC Martensitic Grade steel plate

,

AISI 420HC 5mm plate steel

Leave a Message
Product Description

AISI 420HC EN 1.4034 Stainless Steel Sheets And Plates Martensitic Grade



Martensitic stainless steels combine high hardness and wear resistance with relatively good toughness.They are resistant to corrosion under atmospheric environmental conditions.They are mainly used for blades and knives in household, medical, industrial, and consumer applications.

Because of their high strength, corrosion resistance, good toughness, and very good fatigue properties,they are also used as springs, e.g., as valves in compressors.



EN 1.4034, DIN X46Cr13, AISI 420HC stainless steel, carbon 0.43~0.50, chromium 12.50~14.50 a modified type 420 stainless with more carbon, which obtains HRC 57 after suitable heat treatment.



Grade C Cr
AISI 420A, EN 1.4021 0.16~0.25 12.00~14.00
AISI 420B, EN 1.4028 0.26~0.35 12.00~14.00
AISI 420X, EN 1.4031 0.36~0.45 12.50~14.50
AISI 420C, EN 1.4034 0.43~0.50 12.50~14.50
AISI 420D, EN 1.4037 0.58~0.70 12.50~14.50



Forms of supply



EN 4034 / DIN 1.4034, TYPE 420HC, 420C stainless steel strip, coil, band, sheet and plate



Material AISI 420HC EN 1.4034 Stainless Steel Sheets
Shape Bar,Pipe,Sheet
Grade Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS S32760(Zeron 100),2304,904L
Others: 253Ma,254SMo,654SMo,F50(UNS S32100)F60,F61,F65,1J22,N4,N6 etc
Alloy : Alloy 20/28/31;
Hastelloy: Hastelloy B/ -2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N/g;

Hastelloy B / UNS N10001,Hastelloy B-2 / UNS N10665 /

DIN W. Nr. 2.4617,Hastelloy C,Hastelloy C-4 / UNS N06455 / DIN W. Nr. 2.4610,Hastelloy C-22 / UNS N06022 / DIN W. Nr. 2.4602,Hastelloy C-276 /

UNS N10276 / DIN W. Nr. 2.4819,Hastelloy X / UNS N06002 / DIN W. Nr. 2.4665

Haynes: Haynes 230/556/188;
Inconel Series:
Inconel 600/601/602CA/617/625/713/718/738/X-750,Carpenter 20;
Inconel 718 / UNS N07718 / DIN W. Nr. 2.4668,Inconel 601 / UNS N06601 / DIN W. Nr. 2.4851,
Inconel 625 / UNS N06625 / DIN W. Nr. 2.4856,Inconel 725 / UNS N07725,Inconel X-750 / UNS N07750 / DIN W. Nr. 2.4669,Inconel 600 / UNS N06600 / DIN W. Nr. 2.4816
Incoloy: Incoloy 800/800H/800HT/825/925/926;
GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044
Monel: Monel 400/K500/R405
Nitronic: Nitronic 40/50/60;
Nimonic: Nimonic 75/80A/90/A263 ;
Specification Wire: 0.01-10mm
Strip: 0.05*5.0-5.0*250mm
Bar: φ4-50mm;Length 2000-5000mm
Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm
Sheet: δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm
Product
Characteristics
1.According to the preparation process can be divided into deformation superalloys,
casting superalloys and powder metallurgy superalloys.
2.According to the strengthening mode, there are solid solution strengthening type, precipitation
strengthening type, oxide dispersion strengthening type and fiber strengthening type, etc..
Standard GB,AISI,ASTM,DIN,EN,SUS,UNS etc
Inspection ISO,SGS,BV and so on.
Application High temperature components such as turbine blades, guide vanes, turbine disks, high pressure
compressor disks,machine manufacturing
and combustion chambers used in the manufacture of aviation, naval and industrial gas turbines
Packaging 1. cases packed in wooden cases
2. paper packaging
3. plastic packing
4. foam packaging
Packaging according to customer requirements or products
Delivery 7-25days or according to the product
Payment L/C,D/A,D/P,T/T,Western Union,MoneyGram,According to customer requirements payments
for offline orders.

Advantage of Hot rolled stainless steel sheet:

1. The strength of hot-rolled stainless steel plate is relatively low, and the surface quality is poor (oxidation/low finish), but good plasticity, generally medium-thickness plate, cold-rolled plate: high strength/high hardness, high surface finish, generally thin plate, can be used as Stamping board;

2.The hot-rolled stainless steel plate has a smooth surface, high plasticity, toughness and mechanical strength, and is resistant to corrosion by acids, alkaline gases, solutions and other media. It is an alloy steel that is not easy to rust, but it is not rust-free;

3. It can destroy the casting structure of the steel ingot, refine the grain of the steel, and eliminate the defects of the microstructure, so that the steel structure is dense and the mechanical properties are improved. This improvement is mainly reflected in the rolling direction, so that the steel is no longer isotropic to a certain extent; bubbles, cracks and looseness formed during casting can also be welded under high temperature and pressure.
