DIN EN 10151 Precision Tempered Spring Steel Strip 1.4310 X10CrNi18-8
Place of Origin | Shanghai |
---|---|
Brand Name | TISCO ,BAOSTEEL |
Certification | ISO,BV |
Model Number | 1.4310 X10CrNi18-8 |
Minimum Order Quantity | 2 ton |
Price | Negotiation |
Packaging Details | Standard Seaworthy package or as the customer's requirement. |
Delivery Time | 5-10 working days |
Payment Terms | L/C, T/T, Western Union, D/A |
Supply Ability | 2000 Ton/Month |
Technology | 1.4310 X10CrNi18-8 | Type | Sheet,Rod,Pipe,Coil |
---|---|---|---|
Item | Stainless Steel | Color | Natural |
Shipping | Air,Sea | Thickness | 0.3-3.0mm |
High Light | 1.4310 tempered spring steel strip,X10CrNi18-8 tempered spring steel strip,X10CrNi18-8 spring metal strips |
DIN EN 10151 Precision Stainless Spring Steel Strip 1.4310 X10CrNi18-8
DIN 1.4310 is a corrosion resistant stainless steel with good formability in soft condition.The work hardening is greater than other austenitic stainless steels.DIN 1.4310 stainless is the basis for the excellent usability for spring strip with high tensile strength.
Stainless 1.4310 in annealed condition shows no magnetism and becomes slightly magnetic when is cold formed.
Equivalent PRODUCT STANDARD
EN 10088-2 STAINLESS STEELS - PART 2: TECHNICAL DELIVERY CONDITIONS FOR SHEET/PLATE AND STRIP OF CORROSION RESISTING STEELS FOR GENERAL PURPOSES
DIN EN 10151 Stainless Steel Strip for spring
ISO 6931-2 - Stainless steels for springs, narrow strip
ASTM A666 - Annealed or Cold-Worked Austenitic Stainless Steel Sheet, Strip, Plate, and Flat Bar
JIS G4313 Cold rolled stainless steel strip for springs
MATERIAL STANDARD
W.Nr.1.4310
DIN X10CrNi18-8
AISI 301, UNS S30100
JIS SUS301-CSP
Chemical composition ( typical weight % )
Grade | C | Si | Mn | Cr | Ni | Mo |
1.4310, X10CrNi18-8 | 0.10 | 0.60 | 1.00 | 16.70 | 7.20 | 0.30 |
Delivery forms
precision strip, narrow strip, slit strip, thin strip
Dimension
Thickness: 0.02 to 1.5 mm
Width: 5 to 680 mm
Tolerances are acc. to DIN EN 9445
Closer tolerances on request.
Typical Application
In soft condition:
Stamping and Bending Parts
Simple Deep-Drawing-Parts
In hard condition:
Stamping and Bending Parts
Springs
Membranes
Click Domes
