DIN EN 10151 Precision Tempered Spring Steel Strip 1.4310 X10CrNi18-8

  • DIN EN 10151 Precision Tempered Spring Steel Strip 1.4310 X10CrNi18-8
  • DIN EN 10151 Precision Tempered Spring Steel Strip 1.4310 X10CrNi18-8
  • DIN EN 10151 Precision Tempered Spring Steel Strip 1.4310 X10CrNi18-8
  • DIN EN 10151 Precision Tempered Spring Steel Strip 1.4310 X10CrNi18-8
Place of Origin Shanghai
Brand Name TISCO ,BAOSTEEL
Certification ISO,BV
Model Number 1.4310 X10CrNi18-8
Minimum Order Quantity 2 ton
Price Negotiation
Packaging Details Standard Seaworthy package or as the customer's requirement.
Delivery Time 5-10 working days
Payment Terms L/C, T/T, Western Union, D/A
Supply Ability 2000 Ton/Month
Product Details
Technology 1.4310 X10CrNi18-8 Type Sheet,Rod,Pipe,Coil
Item Stainless Steel Color Natural
Shipping Air,Sea Thickness 0.3-3.0mm
High Light

1.4310 tempered spring steel strip

,

X10CrNi18-8 tempered spring steel strip

,

X10CrNi18-8 spring metal strips
Leave a Message
Product Description

DIN EN 10151 Precision Stainless Spring Steel Strip 1.4310 X10CrNi18-8



DIN 1.4310 is a corrosion resistant stainless steel with good formability in soft condition.The work hardening is greater than other austenitic stainless steels.DIN 1.4310 stainless is the basis for the excellent usability for spring strip with high tensile strength.

Stainless 1.4310 in annealed condition shows no magnetism and becomes slightly magnetic when is cold formed.



Equivalent  PRODUCT STANDARD
EN 10088-2 STAINLESS STEELS - PART 2: TECHNICAL DELIVERY CONDITIONS FOR SHEET/PLATE AND STRIP OF CORROSION RESISTING STEELS FOR GENERAL PURPOSES
DIN EN 10151 Stainless Steel Strip for spring
ISO 6931-2 - Stainless steels for springs, narrow strip
ASTM A666 - Annealed or Cold-Worked Austenitic Stainless Steel Sheet, Strip, Plate, and Flat Bar

JIS G4313 Cold rolled stainless steel strip for springs



MATERIAL STANDARD
W.Nr.1.4310
DIN X10CrNi18-8
AISI 301, UNS S30100

JIS SUS301-CSP



Chemical composition ( typical weight % )

Grade C Si Mn Cr Ni Mo
1.4310, X10CrNi18-8 0.10 0.60 1.00 16.70 7.20 0.30



Delivery forms

precision strip, narrow strip, slit strip, thin strip



Dimension

Thickness: 0.02 to 1.5 mm
Width: 5 to 680 mm
Tolerances are acc. to DIN EN 9445
Closer tolerances on request.



Typical Application
In soft condition:

Stamping and Bending Parts
Simple Deep-Drawing-Parts


In hard condition:

Stamping and Bending Parts
Springs
Membranes
Click Domes
