| Place of Origin: | Jiangsu |
|---|---|
| Brand Name: | ZPSS, Baosteel, Tisco |
| Certification: | MTC, ISC |
| Model Number: | ASTM A693 631 17-7PH 1/2 3/4H |
| Minimum Order Quantity: | 1 TON |
| Price: | Negotiation |
| Packaging Details: | Our Exporting Standard Packaging Each roll is strapped by 3 plasitc bands + wrapped with packing cloth + plywood boxes; |
| Delivery Time: | 7-15 Working Days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 1000 TON / Month |
| Name: | Stainless Steel Strip Coil | Thickness: | 0.3mm ~ 3.0mm |
|---|---|---|---|
| Grade: | ASTM A693 631 17-7PH 1/2 3/4H | Surface: | BA, 2B, HL, 8K，Hairline |
| Perfect Service: | 24*7h Available | Application: | Industry Kitchenware Building Elevator |
| High Light: | 4H Hardness Stainless Steel Strip Coil,ASTM A693 Stainless Steel Strip Coil,ASTM A693 springy metal strip |
||
Stainless Steel Plate Sheet Strip Coil ASTM A693 631 17-7PH 1/2 3/4H Hardness
|
Product Name
|
Sheet Strip Coil ASTM A693 631 17-7PH 1/2 3/4H Hardness |
|||
|
Material(DIN)
|
1.4301/1.4306/1.4541/1.4401/1.4404/1.4571/1.4539/1.4410/1.4833/1.4845
|
|||
|
Thickness
|
0.01 -3.0
|
|||
|
Surface
|
2B, BA, NO.4, Mirror, Hairline, etc
|
|||
|
Standard
|
JIS, AISI, ASTM, GB, DIN, EN, AISI, ASTM, DIN, EN, GB, JIS
|
|||
|
Grade
|
201/304/304L/321/316/316L/310S/904L/309S/316Ti/317L/2205/2507, etc.
|
|||
|
Technique
|
Cold Rolled,Hot Rolled
|
|||
|
Certification
|
ISO9001, SGS, BV, ISO, CE
|
|||
|
Used
|
Building Industry Machinery, etc.
|
|||
|
MOQ
|
1 Ton
|
|||
|
Payment terms
|
L/C at sight or T/T (30% as deposit)
|
|||
|
Container Size
|
20ft GP: 5898mm(Length)x2352mm(Width)x2393mm(High)
40ft GP: 12032mm(Length)x2352mm(Width)x2393mm(High)
40ft HC: 12032mm(Lengh)x2352mm(Width)x2698mm(High) |
|||
|
Delivery time
|
Usually 7-15 working days, or upon negotiation
|
|||
|
Price terms
|
FOB,CRF,CIF,EXW all acceptable
|
|||
Maintaining the superior properties of 18–8 stainless, 17-7PH is the most common precipitation hardening stainless steel that can be hardened through heat treatment. It can be subjected to a variety of heat treatment processes to suit working and applications from the softest solution heat treatment to a hard full-hardened finish. This allows it to acquire strength second only to quenched high-carbon martensitic stainless steels.
In a solution-heat-treated state, 17-7PH is non-magnetic, but demonstrates quite strong magnetic properties after precipitation hardening.
Standard
| EN | DIN | AISI | UNS | JIS | GB |
| 1.4568 | X7CrNiAl17-7 | S17700 | S17700 | SUS631 | 0Cr17Ni7Al |
Chemical composition ( weight % )
| C | Si | Mn | P | S | Cr | Ni | Al |
| 0.09 max | 1.00 max | 1.00 max | 0.040 max | 0.030 max | 16.00~18.00 | 6.50~7.75 | 0.75~1.50 |
Typical mechanical properities
| Property | A | TH 1050 | RH 950 | C | CH 900 |
| UTS | 896 | 1379 | 1620 | 1517 | 1827 |
| 0.2% YS | 276 | 1276 | 1517 | 1310 | 1793 |
| Elongation | 35 | 9 | 6 | 5 | 2 |
| Hardness, Rockwell | B85 | C43 | C48 | C43 | C49 |
FAQ
Q:What is your terms of payment ? A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance based on BL copy or LC at sight. If you have another question, please contact us as below
Q:What about your price? A:Our price is very competitive because we are a factory. Pls feel free to contact us if you are interested in our products. Q:How long is your delivery time?
A:Different products have different delivery time.The products will be delivered as soon as possible on the basis of the quality assurance.Usually the delivery time is within5 days after we received your deposit.
Packing&Delivery
Stainless steel coil be packed with kraft paper, plastic plate and wooden pallet. To be packed strongly avoid damage during transportation, and can be also according to the regulations and customer’s requests. Furthermore, products packages also are tagged clear on the outside for easy identification of the product and quality information.
WUXI XINFUTIAN METAL PRODUCTS CO.,LTD is a professional company for Stainless steel products production, processing and sales which has experienced over ten years of development. We are located in WUXI, close to Shanghai (BAO STEEL),Zhangjiagang (ZPSS),Ningbo (BAO XIN),enjoying excellent geographic location and convenient water, land and air transportation.
The company has modern professional metal processing machines of which the 90% are imported from Japan and Germany. Such as Water Jet machine,Cold/Hot Rolled production line,laser cutting machine,hailrine machine which can provide cutting ,slitting ,polished ,OEM and ODM service for our clients.
Our company presist to the spirit of "Integrity,Pragmatic,High quality,First-class”, providing customers with the most satisfactory service .
Our company has a various range of products including stainless steel sheet and coil,pipe,profiles etc. We are the autorized dealers of BAOSTEEL ,BAOXIN,ZPSS,TISCO etc.Our long-term business lines are 201,202,304(1.4301),304L,316,316L(1.4404),430,409L,309S, 310S(1.4845),317L,904L,2205,2507.
