EN 1.4521 Ferrite Stainless Steel Sheet Plate DIN X2CrMoTi18-2 AISI 444

Place of Origin Shanghai
Brand Name TISCO ,BAOSTEEL
Certification ISO,BV
Model Number DIN X2CrMoTi18-2 / 444
Minimum Order Quantity 2 ton
Price Negotiation
Packaging Details Standard Seaworthy package or as the customer's requirement.
Delivery Time 5-10 working days
Payment Terms L/C, T/T, Western Union, D/A
Supply Ability 2000 Ton/Month
Product Details
Name Stainless Steel Sheet Stock Item Stainless Steel
Color Natural Material 444
Thickness 0.5mm Type Stainless Steel Plate、sheet
High Light

EN 1.4521 Stainless Steel Sheet

,

AISI 444 Stainless Steel Sheet Plate

,

Ferrite Stainless Steel Sheet Plate

Leave a Message
Product Description

EN 1.4521 DIN X2CrMoTi18-2 AISI 444 Stainless Steel Sheet And Plate



APPLICATIONS



Food processing, brewery and wine making equipment, hot-water tanks, heat-exchanger tubing and automotive components



Stainless Steel Sheet Stock Introduction



Product
Stainless Steel Sheet, Stainless Steel Plate
Material Type
Ferrite stainless steel, magnetic; Austenitic stainless steel, Non-magnetic.
Material Origin
TISCO, BAOSTEEL, JISCO, LISCO, BAOSTEEL, ZITAISTEEL
Grade
430, 410S, 409L, 201, 304
Technology
Cold Rolled
Thickness
0.17mm to 2.0mm
Sheet Size
220-1000mm * Customized Length
Surface
BA, 2B, 2D, 4K, 6K, 8K, NO.4, HL, SB, Embossed
Other Choices
Leveling: improve flatness, esp. for items with high flatness request.
Skin-Pass: improve flatness, higher brightness
Protection
1. Inter paper available
2. PVC protecting film available
** The sizes or thicknesses of stainless steel coil can be customized, if you need additional information,please don’t hesitate to
contact us at any time.
** All standard products are supplied without inter paper & PVC film. If needed, please inform.
If your quantity is smaller than our MOQ, kindly pls contact us for inquiry accordingly, thank you.



Stainless Steel Sheet Stock Chemical composition



Type 444 is a low carbon, low nitrogen, ferritic stainless steel that provides pitting and crevice corrosion resistance superior to most ferritic stainless steels. Applications requiring superior corrosion resistance and resistance to chloride stress corrosion cracking are ideal for this alloy.



CHEMISTRY TYPICAL



Carbon: 0.025 max
Manganese: 1.00 max
Silicon: 0.60
Chromium: 17.50-19.50
Nickel: 01.00 max
Molybdenum: 1. 75-2.50
Titanium+ Columbium : 0.20 + 4x (Carbon+ Nitrogen) min-0.80 max
Phosphorus: 0.040 max
Sulfur: 0.030 max
Iron: Balance



FINISHES

# 1 - Hot rolled annealed and descaled. It is available in strip, foil and ribbon. It is used for applications where a smooth decorative finish is not required.
# 2D - Dull finish produced by cold rolling, annealing and descaling. Used for deep drawn parts and those parts that need to retain lubricants in the forming process. # 2B - Smooth finish produced by cold rolling, annealing and descaling. A light cold rolling pass is added after anneal with polished rolls giving it a brighter finish than 2D.
#BA- Bright annealed cold rolled and bright annealed
#CBA- Course bright annealed cold rolled matte finish and bright anneal
#2 - Cold Rolled
# 2BA- Smooth finish produced by cold rolling and bright annealing. A light pass using highly polished rolls produces a glossy finish. A 2BA finish may be used for lightly formed applications where a glossy finish is desired in the formed part. Polished - Various grit finish for specific polish finished requirements.



Stainless Steel Sheet Stock purpose



Decoration board for elevator and escalator

Building decoration board, such as decorative structural parts, structural pipe

Automobile exhaust system components

Washing machine inner drum
