Customized Hot Rolled Stainless Steel Sheet 300 Series 3 - 120MM 317L BA Finish

Place of Origin Shanghai ,Shanxi
Brand Name BAOSTEEL , TISCO ,HONGWANG ,LISCO,
Certification ISO ,SGS,BV
Model Number 300 Series 317L
Minimum Order Quantity 1 ton according to products
Price Negotiation
Packaging Details Export Package
Delivery Time 5-10 working days
Payment Terms L/C, T/T, D/P, Western Union
Supply Ability 2000 T/Month
Product Details
Thickness 3-120mm Finish NO 1
Width 1000mm,1219mm,1250mm,1500mm Color Natural Surface Or As Customized
Standard JIS/ASTM/BN Shape Plate
High Light

stainless steel sheet 2b finish

,

hairline finish stainless steel sheet

Leave a Message
Product Description

Customized Hot Rolled Stainless Steel Plate 300 Series 317L NO1 Finish

1. Products Details

317L (00Cr19Ni13Mo3, UNS S31726) alloy is based on molybdenum-based austenitic stainless steel. It has a stronger resistance to chemical corrosion than conventional chromium-nickel austenitic stainless steels such as 304 alloys. In addition, compared with conventional stainless steel, 317L alloy has a higher ductility, stress corrosion resistance, compressive strength and high temperature performance. It is a low carbon grade or L grade, which has an anti-sensitization performance during and during heat treatment.


Grade317L stainless steel sheet
Thinckness3-120mm
Tolerance+/-0.02mm
Widthness1500mm,1800mm,2000mm or as customized
Length6000mm or as customized
Brand nameTISCO,L;ISCO,BAOSTEEL
StandardJIS, AISI, ASTM, GB, DIN, EN ,etc.
Finish2B, NO1,Hairline, No.4, BA, 8K mirror, etc.
CertificationSGS
PackagingStandard exporting packing; seaworthy package.
MOQ1 Tons
Price timeFOB, CFR, CIF, CNF
Delivery timeWithin 15-20 working days after receiving your deposit
Payment30% T/T in advanced+70% balanced; irrevocable L/C at sight
RemarksInsurance is all risks and accept the third party test

 Chemical Properties: 317L

317LCSiMnPSNiCr
≤0.03≤1.00≤2.00≤0.045≤0.0311.0-15.018.00~20.00


SUS317 L Mechanical properties

YS(Mpa)≥176,TS(Mpa)≥480,EL(%)≥40,Hv≤200

2. APPLICATIONS

Relative 316 l, 317 l steel has excellent water resistance and resistance to SCC, used for Chemical ships, Chemical products, such as Reactor should be high corrosion-resistant Chemical equipment


3. Hot Rolling Production Line For 317L  SHEET


Thickness
(mm)

Witth
(mm)

Length
(mm)

Precision
(mm)

Straightness
(mm)

Length Error
(mm)

Trimedge Thickness
(mm)

3.0-8.0800-16001000-150000≤±1.5≤±1.0≤±1.5≤8.0
6.0-14.01000-2000≤14.0
8.0-18.01250-2000≤16.0


317L SS Sheet  In Stock


NO.1 FinishT*W*LW*LW*L
NO.1 Finish3.0*1500*60001800*60002000*6000
NO.1 Finish4.0*1500*60001800*60002000*6000
NO.1 Finish5.0*1500*60001800*60002000*6000
NO.1 Finish6.0*1500*60001800*60002000*6000
NO.1 Finish8.0*1500*60001800*60002000*6000
NO.1 Finish10*1500*60001800*60002000*6000
NO.1 Finish12*1500*60001800*60002000*6000
NO.1 Finish14*1500*60001800*60002000*6000
