PVD Cold Rolled Stainless Steel Sheet 304 Thickness 2MM with Brass Colour

Place of Origin Jiangsu
Brand Name JISCOTISCO, BAOSTEEL, ZPSS, LISCO, ect
Certification ISO, SG, MTC
Model Number 304,201,202,316
Minimum Order Quantity 1 ton
Price Negotiation
Packaging Details Interlayer paper kraft paper Wooden pallet or according to customer's request.
Delivery Time 7-15 working days
Payment Terms L/C, T/T
Supply Ability 1000Ton Per Month
Product Details
Finish Mill Finish Material Cold Rolled Stainless Steel Sheet 446
Thickness 0.3-6mm Size 1000mm*2000mm, 1219mm*2438mm, 1219mm*3048mm,
Sample Free Sample Color Brass
Process Color Plating Process Pattern According To The Customer Request
High Light

cold rolled stainless steel

,

stainless steel cold rolled sheet

Leave a Message
Product Description

      PVD Cold Rolled Stainless Steel Sheet 304 Thickness 2MM with Brass Colour



  • PVD is the abbreviation of Physical Vapor Deposition. It’s a process to produce a metal vapor (Titanium, Chromium and Titanium Aluminum) that can be deposited on electrically conductive materials as a thin highly adhered pure metal or alloy coating. It’s a process carried out in a vacuum chamber at vacuum using a cathodic arc source.

    The coating compounds are made up of various elements such as carbides, nitrides, borides and silicide. The makeup of the compound varies some depending on what the application necessitates. A wide variety of colors can be achieved by adding other gases during the deposition.

Etching is traditionally the process of using strong acid or mordant to cut into the unprotected parts of a metal surface to create a design in intaglio (incised) in the metal. In modern manufacturing, other chemicals may be used on other types of material. As a method of printmaking, it is, along with engraving, the most important technique for old master prints, and remains in wide use today. In a number of modern variants such as microfabrication etching and photochemical milling it is a crucial technique in much modern technology, including circuit boards.

In traditional pure etching, a metal (usually copper, zinc or steel) plate is covered with a waxy ground which is resistant to acid. The artist then scratches off the ground with a pointed etching needle where he or she wants a line to appear in the finished piece, so exposing the bare metal. The échoppe, a tool with a slanted oval section, is also used for "swelling" lines. The plate is then dipped in a bath of acid, technically called the mordant (French for "biting") or etchant, or has acid washed over it.The acid "bites" into the metal (it dissolves part of the metal) where it is exposed, leaving behind lines sunk into the plate. The remaining ground is then cleaned off the plate. The plate is inked all over, and then the ink wiped off the surface, leaving only the ink in the etched lines.

The plate is then put through a high-pressure printing press together with a sheet of paper (often moistened to soften it). The paper picks up the ink from the etched lines, making a print. The process can be repeated many times; typically several hundred impressions (copies) could be printed before the plate shows much sign of wear. The work on the plate can also be added to by repeating the whole process; this creates an etching which exists in more than one state.



Detailed information



Grade • Grade 304/304L (UNS S30400/S30403, EN 1.4301/1.4307)
• Grade 316L (UNS S31603, EN 1.4404)
• Grade 409L (UNS S40900, EN 1.4512)
• Grade 430 (UNS S43000, EN 1.4016)
• Grade 441 (UNS S44100, EN 1.4509)
Finish • No.1/2D/2B/BA
• Grinding Finish (No.3/No.4/No.5/No.6/SB/HL)
• Mirror Finish
• Vibration/CD Overlay/Bead Blast/Etched Finish/Embossed Finish
Type Sheet Only
Color Gold/Black/Brass/Rose/Champagne
We are continuously researching and developing the process to add more colors. If there is a particular color that you’re interested in developing, please don’t hesitate to contact us.
Thickness 0.3 – 3.0mm
The thickness over 3mm are acceptable upon the request
Sizes Max. 1524 x 4000mm
Special dimensions are acceptable upon the request
PE Coating Double PE or Laser PE coating

PVD Cold Rolled Stainless Steel Sheet 304 Thickness 2MM with Brass Colour 0
