| Place of Origin: | Shanghai ,Shanxi |
|---|---|
| Brand Name: | BAOSTEEL , TISCO ,HONGWANG ,LISCO， |
| Certification: | ISO ,SGS,BV |
| Model Number: | 300 Series 304l |
| Minimum Order Quantity: | 1 ton according to products |
| Price: | Negotiation |
| Packaging Details: | Export Package |
| Delivery Time: | 5-10 working days |
| Payment Terms: | L/C, T/T, D/P, Western Union |
| Supply Ability: | 2000 T/Month |
| Thickness: | 3-120mm | Finish: | NO 1 |
|---|---|---|---|
| Width: | 1000mm,1219mm,1250mm,1500mm | Color: | Natural Surface Or As Customized |
| Standard: | JIS/ASTM/BN | Shape: | Plate |
| High Light: | embossed stainless steel sheets,304 stainless steel plate |
||
ASTM A240 304L Hot Rolled Stainless Steel Plate 4 - 120mm Customized Thickness
1. Products Details
304L is the most versatile and widely used alloy in the stainless steel family. Ideal for a wide variety of home and commercial applications, Alloys 304L exhibits excellent corrosion resistance and has a high ease of fabrication, outstanding formability. The austenitic stainless steels are also considered to be the most weldable of the high-alloy steels and can be welded by all fusion and resistance welding processes.
| Grade | 304L stainless steel sheet |
| Thinckness | 3-120mm |
| Tolerance | +/-0.02mm |
| Widthness | 1500mm,1800mm,2000mm or as customized |
| Length | 6000mm or as customized |
| Brand name | TISCO,L;ISCO,BAOSTEEL |
| Standard | JIS, AISI, ASTM, GB, DIN, EN ,etc. |
| Finish | 2B, NO1,Hairline, No.4, BA, 8K mirror, etc. |
| Certification | SGS |
| Packaging | Standard exporting packing; seaworthy package. |
| MOQ | 1 Tons |
| Price time | FOB, CFR, CIF, CNF |
| Delivery time | Within 15-20 working days after receiving your deposit |
| Payment | 30% T/T in advanced+70% balanced; irrevocable L/C at sight |
| Remarks | Insurance is all risks and accept the third party test |
| 304l | C | Si | Mn | P | S | Ni | Cr |
| ≤0.03 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 8.00~12.00 | 18.00~20.00 |
Pysical properties
| 304l | Tensile Strength: | σb (MPa)≥520 |
| Yield strength : | σ0.2 (MPa)≥205 | |
| Elongation: | δ5 (%)≥40 | |
| Hardness : | ≤187HB;≤90HRB;≤200HV | |
| Density : | 7.93g/cm3 | |
| specific heat capacity | c(20℃)0.502 J·(g·C)-1 | |
| heat conductivity | λ/W(m·℃)-1 | |
| melting point | 1398～1420℃ | |
| 304l | Tensile Strength: | σb (MPa)≥520 |
| Yield strength : | σ0.2 (MPa)≥205 | |
| Elongation: | δ5 (%)≥40 | |
| Hardness : | ≤187HB;≤90HRB;≤200HV |
3. Applications
l Food processing equipment, particularly in beer brewing, milk processing, and wine making
l Kitchen benches, sinks, troughs, equipment, and appliances
l Architectural trim and molding
l Automotive and aerospace structural use
l Construction material in large buildings
l Chemical containers, including for transport
l Heat exchangers
l Nuts, bolts, screws, and other fasteners in the marine environment
l Dyeing industry
l Woven or welded screens for mining, quarrying & water filtration
3. Surface of stainless steel sheet
|
|
|
Characteristics | Applications |
| No. 1 | 3.0mm~150.0mm | Finished by hot-rolling, annealing and pickling, characterized by white pickled surface | Chemical industry equipment,Industrial tanks |
| 2B | 0.2mm~6.0mm | Finished by heat treatment, pickling after cold rolling, followed by skin pass line to be more brighter and smooth surface | General Application Medical Instruments,Tableware |
| BA | 0.5mm~30.0mm | Bright heat treatment after cold rolling | Kitchen utensil, kitchen ware,architectural purpose |
| No.4(Bright Annealed) | 0.4mm~3.0mm | Polishing with No. 150 to No.180 mesh abrasives The most popular finishes | Milk & Food processing acilities, Hospital Equipment, Bath-tub |
| HL(Hair Line) | 0.4mm~3.0mm | Finished by continuous linear polishing | Architectural purposes, escalators, kitchen ware vehicles |
| 8k | 0.5mm~30.0mm | Shinning like a mirror | Building construction |
