| Place of Origin: | WUXI,WENZHOU |
|---|---|
| Brand Name: | AOXIANG |
| Certification: | BV,SGS |
| Model Number: | 201 |
| Minimum Order Quantity: | Negotiable |
| Price: | Negotiation |
| Packaging Details: | Plastic bags |
| Delivery Time: | 5-10 working days |
| Payment Terms: | D/A, L/C, T/T |
| Supply Ability: | 1500ton/Month |
| Name: | Stainless Steel Welded Tube | Thickness: | 0.16-3.0mm |
|---|---|---|---|
| OD: | 8-140mm | Length: | 6m Or As Customized |
| Grade: | 201 | Feature: | Acid Resistance |
| High Light: | 8k Cold Rolled Stainless Steel Pipe,304l 8k Stainless Steel Pipe,c276 Round Stainless Steel Pipe |
||
Round Cold Rolled 8k Mirror Polished 304l c276 316 316l 310s 321 304 310 Stainless Steel Pipe
Stainless Steel Welded Tube Application
Liquid delivery,for food,dairy, and so on
Stainless Steel Welded Tube Details
Chemical composition(WT%)
(C):≤0.15 (Si):≤0.75 (Mn):5.5~7.50 (Cr):16.0~18.0 (N):≤0.25 (Ni):3.0~5.0 (P):≤0.060 (S) :≤0.030
physical property
strength of extension:100,000 to 180,000 psi;
yield strength:50,000 to 150,000 psi;
elongation :55 to 60%
modulus of elasticity:29,000,000 psi;
density :.280lbs/cubic inch(7.93g/cm3)
|
Product Name
|
Stainless steel pipe
|
|
Material
|
201 202 304 304L 316 316L 321 309 310S 410 430 436 436L 904L etc.
|
|
Finish(Surface)
|
Bare, Black, Vanished, 3PE anti-corrosion steel pipe
|
|
Thickness
|
0.3mm-30mm
|
|
Diameter
|
6mm-630mm
|
|
Length
|
1000mm-6000mm or custom
|
|
Standards
|
AISI ASTM JIS SUS DIN GB
|
|
Application
|
For transportation pipelines, engineering structures, thermal equipment, petrochemical industry, machinery manufacturing,
geological drilling, high-pressure equipment and so on |
|
Tips
|
The sizes or diameter and length of stainless steel pipes can be customized, if you need additional information, please don’t
hesitate to contact us at any time. |
|
Grade
|
C
|
Si
|
Mn
|
P
|
S
|
Ni
|
Cr
|
Mo
|
|
201
|
≤0.15
|
≤0.75
|
5.5-7.5
|
≤0.06
|
≤ 0.03
|
3.5-5.5
|
16.0-18.0
|
-
|
|
301
|
≤0.15
|
≤1.0
|
≤2.0
|
≤0.045
|
≤ 0.03
|
6.0-8.0
|
16.0-18.0
|
-
|
|
304
|
≤0.08
|
≤1.0
|
≤2.0
|
≤0.045
|
≤ 0.03
|
8.0-10.5
|
18.0-20.0
|
-
|
|
304L
|
≤0.03
|
≤1.0
|
≤2.0
|
≤0.035
|
≤ 0.03
|
9.0-13.0
|
18.0-20.0
|
-
|
|
316
|
≤0.08
|
≤1.0
|
≤2.0
|
≤0.045
|
≤ 0.03
|
10.0-14.0
|
16.0-18.0
|
2.0-3.0
|
|
316L
|
≤0.03
|
≤1.0
|
≤2.0
|
≤0.045
|
≤ 0.03
|
12.0-15.0
|
16.0-18.0
|
2.0-3.0
|
|
321
|
≤0.08
|
≤1.0
|
≤2.0
|
≤0.035
|
≤ 0.03
|
9.013
|
17.0-1 9.0
|
-
|
|
410
|
≤0.15
|
≤1.0
|
≤1.0
|
≤0.035
|
≤ 0.03
|
-
|
11.5-13.5
|
-
|
|
430
|
≤0.12
|
≤0.75
|
≤1.0
|
≤0.040
|
≤ 0.03
|
≤0.60
|
16.0-18.0
|
-
|
